Operating Instructions
Webasto BlueCool Premium
Chilled Water Marine Air Conditioning Systems
General information
Dear Webasto Customer!
These Operating Instructions provide an overview about how to use the chilled water air
conditioning system and its control panels. An extensive documentation and description can
be found in the Installation and Service Instructions.
To ensure safe use of the appliance, ALWAYS read and follow all instructions
in this manual. It is very important that an authorized Webasto dealer carries
out any repair or maintenance not described in this manual.
Safety notes
In general, all A/C (air conditioning) systems are running on 230 or 115 Volt AC. For all work
at any of the components like pumps, compressor, blowers or electronics, the power
connection has to be interrupted. All work at the electric wiring must be performed by
specialized installers.
Before starting the air condition system, check the following points:
• The closing valve at the sea-cock is open!
• The sea-water strainer is clean and filled with water!
• The boat has enough water under the body and the sea-cock is not blocked!
• All supply and return air grilles are open and not blocked by luggage, clothing or anything
else!
• After turning the system on, water comes out of the over-board discharge. If not, switch
off the system and check the sea-water circuit again!
Designated Control Panels
The chiller unit is operated and controlled by the Chiller Control digital control panel.
Directly connected air handlers for one cabin are also operated by this control panel.
Other cabins with indirectly connected air handlers are controlled by separate Cabin
Control digital control panels.
The system must be started with the Chiller Control prior to normal functionality of
the air handlers in other cabins.
Advertisement
Related Manuals for Webasto BlueCool Premium
Summary of Contents for Webasto BlueCool Premium
-
Page 1: Operating Instructions
Installation and Service Instructions. To ensure safe use of the appliance, ALWAYS read and follow all instructions in this manual. It is very important that an authorized Webasto dealer carries out any repair or maintenance not described in this manual. - Page 2 Chiller Control: Start and stop of the chiller unit • Programming and setup of the chiller unit • Setup of directly connected air handlers • Selection of operation mode (Automatic, Cooling, Heating) Cabin Control: • Start and stop of indirectly connected air handlers •...
-
Page 3: Setting The Temperature
Operating the „Chiller Control“ When the air conditioning is connected with the electrical power, the system initializes itself. The display shows Init and afterwards the frequency, e.g. Starting Press once the button. 28.5 is displayed and after appr. 20 sec. the current room temperature, e.g. (°C) (83 ºF) is shown. - Page 4 „Cabin Control“ for indirectly connected air handlers Illustration see paragraph „Chiller Control“ for chiller and directly connected air handlers. The digital control panel is always factory pre-programmed and the secondary commands are code-protected. Starting Press once the button. 28.5 is displayed and after appr. 20 sec. the current room temperature, e.g. (°C) (83 ºF) is shown.
-
Page 5: Error Code Display And Actions
Error code display and actions The error codes are viewed on the display screen. After the error codes are displayed, the sys- tem is shut off for 60 sec. and re-started (except for ba11). If the same error occurs more than 6 times within 60 minutes, the A/C system will be completely stopped. -
Page 6: Warranty Claims
Warranty claims Failure to follow the Installation Instructions and the information, recommendations and descriptions therein will void all warranties. The same applies if repairs are carried out incorrectly, with the use of non-genuine parts or by unauthorized personnel. Warranty claims are only valid if the claimant can verify that he has complied with the maintenance and safety instructions.
