E l e c t r i c a l S p e c i f i c a t i o n s
I M 4 8 3 H D C E l e c t r i c a l C h a r a c t e r i s t i c s
Specification
Input Voltage
Phase Output Current
Phase Output Current
Supply Current (+5V)
Active Power Dissipation
Low Level Input Voltage
High Level Input Voltage
High Level Input Voltage
Low Level Input Current
Input Pull-Up Resistance
Input Pull-Up Resistance
Input Pull-Up Resistance
Low Level Output Current
High Level Output Current
Low Level Output Voltage
High Level Output Voltage
Fan Operating Voltage
Fan Operation Current

Table 2.1: IM483H DC Electrical Characteristics

*Includes Motor Back EMF.
**Lower Currents may be used for Current Reduction.
Test Condition
RMS
Peak
Inputs/Outputs Floating
I =3A RMS
OUT
All Inputs
All Inputs Except Reset
Reset
SCLK,DIR,H/F, Enable
Fault, MSEL 0-3, Enable
Step Clock, Direction
Reset Input Only
Fault, Fullstep
Fault, Fullstep
Fault, Fullstep
Fault, Fullstep
IM483H/IM805H Rev. R032206
Min. Typ. Max.
+12 +45 +48*
0.4** 3
4
100
50 80
0.8
2.0
2.3
-1.2
4.94 4.99 5.03
2.19 2.21 2.23
1.27
-6
3
0.4
4.5
4.3 5.0 5.7
170
Unit
VDC
A
A
mA
mA
V
V
V
mA
kΩ
kΩ
kΩ
mA
mA
V
V
V
mA
9
