TECNOEKA Srl ______________________________________________________________ use and instruction manual

1. Technical service

A technical check-up once or twice a year helps prolong the life of the appliance and guarantees
better operation. Make sure that assistance is carried out solely and exclusively by qualified
personnel. For any spare parts orders or for any information about the appliance, always mention
the serial number and model (data indicated on the "technical data" plate at the rear of the oven).
2. General warnings
Very important!: keep this instruction book together with the appliance for future consultation.
These warnings were drafted for your safety and for that of others. Please read them carefully
before installing or using the appliance:
- If, on receipt of the goods, the packaging is damaged, write the following on the delivery
note: "I REVERSE THE RIGHT TO CONTROL THE GOODS", specify the damage and get the
driver to sign in acceptance; send a claim in writing to the seller within 4 calendar days from
the date of receipt. No claim shall be accepted after such period.
- The warehouse inside temperature must not be lower than -9°C; otherwise, the thermostat
(regulation and safety thermostat) control devices of the machine will be damaged. Failure to
observe this prohibition invalidates any responsibility of the manufacturer of the machine.
- The appliance is intended for professional use and must be utilised by qualified personnel
trained to use it.
- Any modification which may be necessary on the electrical system to enable installation of the
appliance, must be carried out solely by competent personnel.
- It is dangerous to modify or attempt to modify the characteristics of this appliance.
- Never clean the appliance with direct water jets, because, if any water enters, it could limit the
machine's safety .
- Before doing any maintenance or cleaning jobs, disconnect the appliance from the electrical
mains and allow it to cool.
- When the tilting door is wide open, do not put anything on the surface, because the door
hinges could be irreparably damaged.
- Do not attempt to carry out the periodic controls or any repairs by yourself. Contact the
nearest Service Centre and use only original spare parts.
N.B.: Improper or incorrect use and failure to observe the installation instructions shall release the
manufacture from all responsibility. In this connection, the directives in the "POSITIONING"
paragraph must be strictly observed.
3. Technical specifications
Models
Dimensions of appliance LxDxH
(mm)
Weight (Kg)
Maximum load per tray
Maximum load (kg)
Convection heating element
(kW)
Max. absorbed power (kW)
Power supply voltage (V)
Power cable diameter
Type of cable
Connecting electric cable
Class
Degree of protection against
humidity
Water pressure (kPa)
The noise level of the appliance in operation is below 70 dB (A).
The "technical data" plate is positioned on the side panel of the appliance.
page. 4 ________________________________________________________________________________________
EKF423DUD EKF443DUD
590x703x59 675x725x55
0
38 40
1,5
(kg)
6
2,7
2,9 3,2
230 V (50/60Hz)
3x1,5 mm
EKF411DALUD
EKF311DUD
EKF416DALUD
EKF364DUD
EKF464DALUD
790x752x504 784x770x637
7
44
4 -2
12 - 6
3 3,5
3,7
2
H07RN-F
100-200
EKF411DUD
EKF416DUD
EKF464DUD
57
4 – 2
16 - 8
6
6,4
230 (50/60Hz)
400 2N (50/60Hz)
2 2
3x4mm – 4x2,5 mm
Tipo Y
I
IPX3
EKF 464 D UD/001
EKF464DUD/0/037
EKF 411 DUD/0/037
EKF 464 DALUD/0/037
784x752x634
58
230 (50/60Hz)
2
3x4mm
