TECNOEKA Srl ______________________________________________________________ use and instruction manual
temperature 30°C higher than cooking temperature) to obtain maximum uniformity. Do not salt
foods in the cooking compartment.

6. Residual risks (for the user)

After a cooking operation, open the door cautiously, to avoid a violent outflow of heat which
could cause burns. While the oven is in operation, pay attention to the possible hot zones (marked
on the appliance) of its external surfaces. Place the machine on a bench or similar support, at a
height of at least 85 cm from the floor. The bench or support must be able to support the weight
of the machine and house it correctly. The appliance contains electrical parts and must never be
washed with a jet of water or steam. The appliance is electrically connected: before attempting any
cleaning operation, cut power to the appliance. Do not use the door handle to move the appliance
(the glass panel may break). When the tilting door is wide open, there is the risk that things could
be placed on the surface with the risk of irreparably damaging the door hinges.
7. How to use the control panel
Control Panel symbol legend:
1 2
Parameter on signal LED
1)
Cooking parameter selection button
2)
Step on signal LED
3)
Cooking step selection button
4)
Parameter display
5)
Parameter value decrease button
6)
8. Ignition
The control panel (digital) automatically turns on as soon as the oven is electrically powered.
The display shows in succession the following written:
- "r.X.X" where "X.X" indicates the firmware revision number inserted in the electronic board (eg
"r.1.0").
- "d.XX" where "XX" is the abbreviation for the card calibration of the model.
Then "0.00" appears on the display to indicate time (expressed in hours and minutes) and the time
led turns on in the parameter field (symbol
The phase 1 led turns on in the "phase" field (set to receive cooking parameters).
9. Switch-off
The control panel automatically turns off10 minutes after the cooking cycle ends (in "manual"
mode or in "automatic" mode whether switched-off automatically or by pressing the
without any button being pressed.
The display and operating function leds turn off. Only the
To restart the control panel, simply press the
page. 8 ________________________________________________________________________________________
3 4 5
6 7
7)
8)
9)
10)
11)
8 9 10
Parameter value increase button
Cooking program select/save button
Manual humidifying button
START/STOP button
Probe core outlet (
for ovens predisposed
).
button led remains on.
button.
11
)
button)
