7-3. Description of the operation keys

6.QUIT
5.ENTER
4.LOCK
No
1 HOME
2 Direction key
3 START/STOP (USB DRIVE)
4 LOCK
5 ENTER
6 QUIT(LOCAL)
20
1. HOME
2. Direction key
3.START/STOP
(USB DRIVE)
Name
Press the main key to return to the home menu.
Used for item selection during setup and cursor movement during
playback.
Press to start recording during free-running, and press to stop
recording. If the instrument is connected to a PC via a USB cable
and the key is pressed during boot-up while the power is turned on,
the instrument goes into USB Drive Mode, allowing the built-in driver
to be used as mass storage.
Hold down this button for at least 3 seconds to set/release the key
lock.
Carries out decisions during setup and confirmed process.
Press this key to cancel the settings, and when the device is set to
remote (key lock), its external operation state, and to return to the
normal state (local).
Description
