Figure 4.8: Colr Settings For Ccww Or Cwww - eldoLED LINEARdrive User Manual

CCWW or CWWW
CCWW: one DMX channel is used for two LED groups with the same colour and one
DMX channel is used for two LED groups consisting of white LEDs only.
CWWW: one DMX channel is used for one LED group and one DMX channel is used
for three LED groups consisting of white LEDs only.

Figure 4.8: COLR settings for CCWW or CWWW

CW lets you set the proportion of colour to white, and INT (intensity) lets you set the
intensity of the light output: 255 is full on, 0 is off.
32
M
Color / white
CW -
+
0...1023
M
Intensity
INT
-
+
0...255
M
display off
