3.4 Replacing the strain reliefs

To replace the strain reliefs:
1. On both sides of the LINEARdrive, make sure the leads run between the strain reliefs'
screw holes.
2. Place the strain relief over the leads.
3. Fasten the strain reliefs' screws.
4. Replace the LINEARdrive's cover.
24

Figure 3.7: Fastening the strain reliefs

2
1
