3.1.2 LINEARdrive 720

Connector
VDC
EXT in
DALI in
DALI out
DMX in
LedSync out
LED (Group x)

3.2 Removing the strain reliefs

Strain reliefs prevent leads from being pulled out by accident. Before you can connect any
leads, you need to remove the strain reliefs.
To remove the strain reliefs:
1. Remove the cover as described in 2.2 "Removing the cover".
2. Use a phillips crosshead screwdriver to unscrew the screws that fasten the strain re-
liefs to the base unit.
3. Take the strain reliefs out.
18
Wire core
diameter in mm
0.14 - 0.5 26 - 20
0.14 - 0.5 24 - 20
0.14 - 0.5 24 - 20
0.14 - 0.5 24 - 20
0.14 - 0.5 24 - 20
0.14 - 0.5 24 - 20
0.14 - 1 26 - 18
Insulation material to be
AWG
stripped away in mm
11
9
9
9
9
9
10
