To enter the SETUP menu:
1. Press the M and + button simultaneously.
2. The display displays LED. This menu option configures the LED groups. Possible val-
ues are:
a. 1-1L: one DMX channel is used for one LED group (group 1). The other LED
group connectors are disabled.
b. 2-2L: two DMX channels are used for two LED groups, the group 1 and group 2
connector. Group 3 and 4 are disabled.
c. 3-3:L: three DMX channels are used for LED groups 1, 2 and 3. Group 4 is dis-
abled.
d. 4-4L: one DMX channel is used per LED group.
e. 2-4L: two DMX channels are used for four LED groups, one for group 1 and 2,
the other for group 3 and 4.
f. 1-4L: one DMX channel is used for four LED groups.
g. RGB: 3 DMX channels are used for three LED groups: one channel for red
LEDs, one for green LEDs and one for blue LEDs.
h. RGBW: four DMX channels are used for four LED groups: one channel for red
LEDs, one for green LEDs, one for blue LEDs and one for white LEDs.
i. RGBA: four DMX channels are used for four LED groups: one channel for red
LEDs, one for green LEDs, one for blue LEDs and one for amber LEDs.
j. RRGB: three DMX channels are used for four LED groups: two channels for red
LEDs, one for green LEDs and one for blue LEDs.
k. RGGB: three DMX channels are used for four LED groups: one channel for red
LEDs, two for green LEDs and one for blue LEDs.
l. CCWW: one DMX channel is used for two LED groups with the same colour and
one DMX channel is used for two LED groups consisting of white LEDs only.
m. CWWW: one DMX channel is used for one LED group and one DMX channel is
used for three LED groups consisting of white LEDs only.
3. Press M to confirm the LED group configuration of your choice.
4. The EXT INP menu item allows you to configure the LINEARdrive for use with an ex-
ternal input device such as a 10k
(10V) or a show switch (SWIT). The first two allow you to turn on/off and dim the light,
the last one to select another show sequence. Confirm your choice by pressing M.
When the EXT INP menu item is set to another value than OFF, but no device is
connected to the EXT connectors, the driver/controller will not yield the optimum
light output.
Ω
potentiometer (POTM), a 0...10V control device
