Appendix
BOGE Operating instructions for C 15 series screw compressors
7.1
101 Intake air INLET
102 Compressed air OUTLET
1 Suction filter
3 Suction filter monitoring (FOCUS only) *
4 Suction controller
5 Ventilation and regulation control valve
6 Direction of rotation monitoring with double check valve (FOCUS only) *
7 Drive motor
8 Air end
9 Final compression temperature display and switch
10 Combined compressed air/oil receiver
11 Oil separator
12 Safety valve
16 Thermostatic oil control valve
17 Oil cooler
18 Oil filter
19 Oil filter monitoring (FOCUS only) *
20 Pressure gauge reading in display
21 Minimum pressure check valve
22 Compressed air after-cooler
23 Pressure transmitter system pressure (FOCUS only)
24 Pressure transmitter net pressure
25 Stop valve, compressed air outlet
27 Oil drainage
28 Throttle with filter
* Option
Flow chart
Page 65
