Product description
Control of compressors
with frequency control
(C 15 F)
Short operating times
General
Safety temperature
limiting device
Page 20
2.4
When the operating pressure psoll (target value) is exceeded the control be-
comes active and reduces the speed.
When the operating pressure p
becomes active and increases the speed..
The settings for p , p
min max
the FOCUS control..
The standard settings are:
p – 4 psig = p
max soll
p – 6 psig = p
max min
WARNING!
During short operating times, the compressor does not reach its operating
temperature. It operates below the dew point. The generated condensate
mixes with the oil. The lubricating ability of the oil is reduced. This leads to
damage on the air end. It is of utmost importance to consult BOGE, if you
operate your system with short operating times.
2.4 Safety and monitoring devices
The safety devices guarantee a high degree of operational safety, in connec-
tion with the BOGE monitoring system.
When one of the safety devices responds, the control system reacts as follows:
– The compressor is immediately switched off.
– A flashing fault number in the left field of the display indicates the cause of
the fault.
WARNING: Risk of injury!
Do not operate the compressor without built-in safety devices!
Do not dismantle the safety devices or put them out of operation!
The following monitoring devices are standard for BOGE control systems:
The safety temperature limiting device switches off the compressor once the
maximum admissible final compression temperature has been reached. In
case the necessary minimum temperature to run the compressor is not guar-
anteed, the compressor does not start.
– Rectify the fault.
– Acknowledge fault by pressing ENTER key
– Switch on the compressor (ON key).
Safety and monitoring devices
(target value) is dropped below the control
soll
and p (target value) are made by parameterization of
soll
