Maintenance
Cleaning the com-
pressed air/oil cooling
unit
Checking the safety
valve
Page 60
6.3
Cleaning:
– After 1500 operating hours, however, at the latest after one year.
NOTICE!
The service life of the compressed air/oil cooling unit depends on the degree
of soiling (dust, oil vapour) of the suctioned cooling air. Extreme external soil-
ing of the cooling unit leads to an increased temperature in the oil circuit.
– Switch off the compressor using the OFF button.
WARNING: Risk of injury!
Prior to any maintenance and servicing work take all necessary safety pre-
cautions described on page 44!
WARNING!
Do not use any sharp objects for cleaning!
These could damage the cooling unit.
Fig. 6.9: Cleaning the compressed air/oil cooling unit
Check:
– After approx. 3000 operating hours, however, at least once a year.
Check safety valve by opening the screw plug.
WARNING: Risk of injury!
Danger of burning due to hot oil!
Take extreme care when checking the safety valve with the compressor run-
ning taking all safety measures into consideration.
Always wear safety gloves!
A hot air-oil mixture escapes when opening!
Maintenance work compressor
–
If the cooling unit is exces-
sively soiled (cleaning is no
longer possible with com-
pressed air), have it disas-
sembled and cleaned by
BOGE service.
BOGE Operating instructions for C 15 series screw compressors
Blow down the dirt with
compressed air in the
opposite direction to the
normal cooling air flow.
Vacuum out the dirt using
an industrial vacuum
cleaner.
