Eizo CuratOR EX2620-3D Instructions For Use Manual page 15

Rear (Continued)
11 12
22 23
22. DC OUT terminal
23. VIDEO input terminal
(BNC type)
24. Y/G input terminal
(BNC type)
25. P /B input terminal
B
(BNC type)
26. P /R input terminal
R
(BNC type)
27. SYNC input terminal
(BNC type)
28. SDI 1/2 input terminal
(BNC type)
29. SDI 1/2 output terminal
(BNC type)
30. DVI-D 1/2 input terminal
(DVI-D)
31. DVI-D 2 output terminal
(DVI-D)
32. Potential equalization
terminal
Note
• Furthermore, for a VIDEO, Y/G, P
with internal 75 Ω. If a cable is connected to the output terminal, the internal terminal automatically opens. When a
cable connected to the output terminal is not connected to a video device, and when the connected video device is
not terminated with 75 Ω, the signal level becomes too large and cannot be displayed correctly.
13 14 15 16 17
24 25 26 27
Used to supply 5V power to a peripheral.
Attention
• No device making contact with a patient may be connected to the DC OUT
terminal.
The signal input to VIDEO input terminal is output as is.
The signal input to Y/G input terminal is output as is.
The signal input to P
The signal input to P
The signal input to SYNC input terminal is output as is.
Connects devices having SDI output terminals.
The signal input to SDI 1/2 input terminal is output as is.
Connects devices having DVI-D output.
The signal input to DVI-D 2 input terminal is output as is.
This is a terminal for ensuring equal potential between the monitor and other
devices. Connects equipotential plugs.
/B, P /R input terminal, when not connected to any output terminal, terminated
B R
18 19 20
28 29 30
/B input terminal is output as is.
B
/R input terminal is output as is.
R
21
31 32
Chapter 1 Introduction
15
