Instructions for Use
Color LCD Monitor
Important
Please read this "Instructions for Use", and "Installation Manual"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• For monitor adjustment and settings, refer to the "Installation
Manual". The "Installation Manual" is part of the "Instructions for
Use".
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eizo CuratOr EX4342
Summary of Contents for Eizo CuratOr EX4342
- Page 1 Instructions for Use Color LCD Monitor Important Please read this “Instructions for Use”, and “Installation Manual” (separate volume) carefully to familiarize yourself with safe and effective usage. • For monitor adjustment and settings, refer to the “Installation Manual”. The “Installation Manual” is part of the “Instructions for Use”.
- Page 2 EIZO GmbH. EIZO GmbH is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO GmbH’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO product specifications are subject to change without notice.
-
Page 3: Precautions
PRECAUTIONS IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • To ensure personal safety and proper maintenance, please read carefully this section. Markings and symbols Symbol This symbol indicates... - Page 4 If the unit is installed incorrectly, it may drop or fall over, resulting in personal injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
- Page 5 WARNING Use the enclosed AC adapter. The enclosed AC adapter (AHM250PS48T) is for use with this product only. Do not use the AC adapter with other equipment. Do not use an AC adapter designed for other devices with this product. Connecting to power sources that do not match the power ratings of the AC adapter may result in fire or electric shock.
- Page 6 CAUTION Check the operational state before use. • Begin use after ensuring that there are no problems with the displayed image. • When using multiple units, begin use after ensuring that the images are displayed appropriately. Securely fix cables / cords that have a fixing feature. If they are not fixed securely, cables / cords may disconnect, and subsequently images may be cut off and your operations may be disrupted.
- Page 7 CAUTION Do not subject the LCD panel to strong impact. Otherwise, glass will break and may result in injury. Periodically clean the area around the power plug and the ventilation slot of the monitor and the AC adapter. Dust, water, or oil on the plug may result in fire. Unplug the unit before cleaning it.
-
Page 8: About The Monitor
About the Monitor Intended use Intended purpose The EX4342 is intended for the display of still images and moving images from various commercially available devices commonly used in a medical environment, in particular endoscopic.The monitor is optimized for the reproduction of colour images. The monitor is not suitable for mammography. Intended patient population and medical conditions The monitor can be used for the intended purpose irrespective of age, body weight and gender. -
Page 9: Precautions For Use
• The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on the LCD panel, this is not a malfunction. -
Page 10: Cleaning
Cleaning Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. Gently wipe off any dirt on the cabinet or panel surface with a soft cloth soaked in a small amount of water or one of the cleaning agents and disinfectants listed below. Recommended cleaning agents and disinfectants Tested cleaning agents and Agent class... -
Page 11: Table Of Contents
CONTENTS PRECAUTIONS ............3 IMPORTANT .............. 3 About the Monitor ..........8 Intended use ............. 8 Precautions for Use ..........9 Cleaning ..............10 CONTENTS ............11 Chapter 1 Introduction ........12 1-1. Features ............12 1-2. Package Contents ........13 1-3. Controls and Functions ......13 Chapter 2 Installation / Connection .... -
Page 12: Chapter 1 Introduction
Chapter 1 Introduction 1-1. Features ● High-quality and high-resolution Ultra High Definition (UHD) • The UHD LCD display allows for display of high-quality, high-resolution medical images. • Equipped with front protection panel • LED Backlight • High luminosity ● Supports multiple I/O •... -
Page 13: Package Contents
1-2. Package Contents Check that all of the following items are included in the package. Note • It is recommended that the box and packing materials be stored so that they can be used to move or transport this product. •... - Page 14 Front *The control panel key is located to the lower right on the back of the housing frame. 1. PRESET button Displays the preset menu. 2. INPUT button Displays the input select menu. 3. MENU button Displays the main menu. 4.
- Page 15 Rear 13 14 10. Grounding screw The additional protective conductor is connected to the grounding screw. 11. Equipotential terminal The equipotential terminal is used when electric potential between electric devices differs and therefore needs to be equalized. This prevents differences in the potential between devices and conductive parts and minimizes the ground resistance.
-
Page 16: Chapter 2 Installation / Connection
Chapter 2 Installation / Connection 2-1. Before Installing the Product Carefully read “PRECAUTIONS” (page 3) and always follow the instructions. When installing this product, perform thorough operational testing (of the system, cables, arms, etc.) in the environment where the product will be used. ●... -
Page 17: Installing The Product
2-2. Installing the Product This product should be installed using an arm or stand. Attention • When installing, do so by carefully following the information in the User Manual about the arm or stand. • Ensure the following and select components that comply with the VESA standards. - Clearance between the screw holes: 400 mm ×... -
Page 18: Connecting The Power Cord
2-3. Connecting the Power Cord Attention • Turn off the monitor before connecting it. • When removing the power cord, always remove the power plug from the power outlet first. Connect the power cord to the AC IN terminal on the AC adapter. Insert the power cord all the way to the back. -
Page 19: Connecting The Cables
2-4. Connecting the Cables Connect the cables appropriate for the device to be used. If you connected the HDMI cable to the monitor, be sure to secure the HDMI cable with the HDMI cable holder. HDMI cable holder Attention • Do not use damaged cables. •... -
Page 20: Installing The Cable Cover
2-5. Installing the Cable Cover Align the cable cover on the back of the monitor in such a way that the cables can go through the cable outlet port. Insert the cable cover tabs into the grooves in the monitor. Tighten the screws at the left and right-hand holes on the bottom side of the monitor. -
Page 21: Chapter 3 If No Image Is Displayed
Chapter 3 If No Image Is Displayed Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Check whether the DC OUT terminal and DC IN terminal are connected properly. • Turn on the power switch. •... -
Page 22: Chapter 4 Specifications
Chapter 4 Specifications 4-1. Specifications List Monitor LCD Panel Type Color (IPS) Backlight Size 109.2 cm (43 inch) Display resolution (H x V) 3840 × 2160 Display Size (H x V) 962.0 mm × 554.8 mm Pixel Pitch 0.2451 mm × 0.2451 mm Viewing Angles 178˚... - Page 23 AC adapter Power Input 100 - 240 VAC ± 10%, 50 / 60 Hz, 3.0 A Maximum Power 140 W or less Consumption Physical Specifications External dimensions 223.0 mm × 37.0 mm × 88.5 mm (W × H × D) Net Weight Approx.
-
Page 24: Displayable Input Signals
4-2. Displayable Input Signals P : Supported -: Not Supported Vertical Scan Resolution Scan Format DisplayPort HDMI DVI-D Frequency (Hz) 640 × 480 Progressive 59.940 800 × 600 Progressive 60.317 1024 × 768 Progressive 60.004 1280 × 800 Progressive 59.810 1280 ×... -
Page 25: Appendix
Appendix Medical Standard • Anyone who connects additional equipment to the signal input parts or signal output parts when configuring a medical system is responsible for ensuring that the system complies with the requirements of IEC/EN60601-1. • Power-supplied equipment can emit electromagnetic waves that could influence, limit or result in malfunction of the monitor. -
Page 26: Emc Information
EMC Information The performance of the EX4342 ensures appropriate display of images. Intended Use Environments The EX4342 is intended to be used in professional healthcare facility environments such as clinics and hospitals (including use in the vicinity of high-frequency surgical equipment such as electrosurgical knives). - Page 27 Technical Specifications Electromagnetic emissions The EX4342 is intended for use in the electromagnetic environment specified below. The customer or the user of the EX4342 should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment - Guidance RF emissions Group 1 The EX4342 uses RF energy only for its internal function.
- Page 28 Electromagnetic immunity The EX4342 has been tested at the following compliance levels according to the testing requirements for professional healthcare facility environments defined in IEC / EN60601-1-2. Customers and users of the EX4342 must ensure that the EX4342 is used in the following environments: Immunity test Test level for Compliance level...
- Page 29 Recommended separation distances between portable or mobile RF communication equipment and the EX4342 The EX4342 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the EX4342 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the EX4342.
-
Page 30: Warning For Radio Interference
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class A digital device. - AC Cord... -
Page 31: 中国在 Chinarohs 中为 Rohs 合规性采取的措施
中国在 ChinaRoHS 中为 RoHS 合规性采取的措施 关于电器电子产品有害物质限制使用标识 本标识根据 「电器电子产品有害物质限制使用管理办法」 ，适用于在中华人民共和国销售的电器电子 产品。标识中央的数字为环保使用期限的年数。只要您遵守该产品相关的安全及使用注意事项，在 自制造日起算的年限内，不会产生对环境污染或人体及财产的影响。上述标识粘贴在机器背面。 下表是依据 SJ/T 11364-2014 的规定编制。 产品中有害物质的名称及含量 部件名称 有害物质 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 （Pb） （Hg） （Cd） （Cr （ VI） ） （PBB） （PBDE） 印刷电路板 〇 〇 〇 〇 〇 〇 机箱... - Page 32 CuratOR EX4342 Instructions for Use Carl-Benz-Straße 3, 76761 Rülzheim, Germany 1086011-001 Copyright © 2022 EIZO GmbH. All rights reserved. 1st Edition - February, 2022...
