Summary of Contents for Eizo CuratOR EX3141-3D
- Page 1 Installation Manual Color LCD Monitor Important Please read this “Installation Manual”, and “Instructions for Use” (separate volume) carefully to familiarize yourself with safe and effective usage. Refer to the “Instructions for Use” for information on the installation / connection of the monitor.
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Table Of Contents
CONTENTS CONTENTS ............. 3 Chapter 1 Basic Adjustment / Setting ....4 1-1. Loading the Monitor Settings ...... 4 1-2. Switching Input Signals ....... 5 1-3. Using Function Buttons ....... 5 1-4. 3D/2D Switching ..........6 Chapter 2 Advanced Adjustments / Settings ... 7 2-1. -
Page 4: Chapter 1 Basic Adjustment / Setting
Chapter 1 Basic Adjustment / Setting This chapter describes the basic functions that can be adjusted and set by pressing the buttons on the front of the monitor. 1-1. Loading the Monitor Settings It is possible to switch to PRESET, FACTORY, or the USER settings that have been set in advance. PRESET Basic settings are made in advance at the factory. -
Page 5: Switching Input Signals
1-2. Switching Input Signals Select the signal input to the monitor and display it on the screen. Press (INPUT). The “Input Select” menu appears. Press to select an input signal. This switches to the selected input signal. Press (INPUT). The menu screen exits. Note •... -
Page 6: 2D Switching
1-4. 3D/2D Switching Switch between 3D and 2D. Press 3D/2D ( (ENTER) ) button. 3D and 2D are toggled each time this button is pressed. Note • 3D mode indicator ( ) is displayed on the upper left of the screen in 3D mode. Chapter 1 Basic Adjustment / Setting... -
Page 7: Chapter 2 Advanced Adjustments / Settings
Chapter 2 Advanced Adjustments / Settings This chapter describes advanced monitor adjustments and settings procedures using the main menu. 2-1. Operation via the Main Menu Menu display 1. Press (MENU). The main menu is displayed. 2. Press to select the desired item, and then press Adjustments / Settings 1. -
Page 8: Functions Of The Main Menu
2-2. Functions of the Main Menu ● Adjustments / settings for 3D display. Function Settings Description 3D/2D Selection Switches 3D/2D display. Signal Format SIMUL Sets the signal format in 3D mode. TOP AND BOTTOM • “SIMUL” SIDE BY SIDE Displays in 3D mode by inputting left-eye signals from DVI-D 1 LINE BY LINE or SDI 1 and right-eye signals from DVI-D 2 or SDI 2. -
Page 9: Video Config
● Video Config Adjustments / settings for image display. Function Settings Description Color 0 to 100 Adjusts image color depth. Tint 0 to 100 Adjusts skin tone. Brightness 0 to 100 Adjusts dark (black) areas of the image. Picture 0 to 100 Adjusts image contrast. -
Page 10: System Config
● System Config Settings for devices. Function Settings Description Function Sets functions assigned to function buttons. Display Direction • “POP” Scan Size Switches between dual screen (P out P: Splits screen Gamma Select horizontally) and single screen display. Color Gamut • “Display Direction” Noise Reduction Rotates / flips the screen. - Page 11 Function Settings Description Power Save Mode Sets whether the backlight turns off after 30 seconds of no video signal. Language English Sets the language to be used for display in settings and all Japanese menus. German French Simplified Chinese Italian Spanish Swedish Traditional Chinese...
-
Page 12: Window Config
● Window Config Screen display settings. Function Settings Description Multi Window Sets dual screen display. • “Off ” Sets single screen display. • “POP ” Displays a split screen (P out P). Display Direction Normal Sets the rotation angle or horizontally flips the main screen and 180°... -
Page 13: Preset
Attention • In dual screen display, the combinations of displayable signals are limited. √: Displayable Subscreen HDMI SDI 1 SDI 2 DVI-D 1 DVI-D 2 DisplayPort Main SDI 1 √* √* √ √ √* √* Screen SDI 2 √* √ √... -
Page 14: Control
● Control Settings for the lock function, and control functions when this device is controlled by an external device. Lock Setting Description Prevents changing settings via the main menu. COM Port Setting Description Settings for the port when used as a COM port. RS-232C Attention •... -
Page 15: Chapter 3 Troubleshooting
Chapter 3 Troubleshooting 3-1. No Picture Displayed Problem Possible cause and remedy 1. No picture. • Check whether the power cord is connected properly. • Check whether the DC OUT terminal and the DC IN terminal are connected properly. • Turn on the power switch. •... -
Page 16: Imaging Problems
3-2. Imaging Problems Problem Possible cause and remedy 1. The screen is too bright or too dark. • Use “Brightness” or “Backlight” in the Setting menu to adjust 2. Text is blurred • Check whether the PC is configured to meet the resolution and vertical scan frequency requirements of the monitor (see “Compatible Resolutions”... -
Page 17: Chapter 4 Reference
Chapter 4 Reference 4-1. Main Default Settings PRESET / FACTORY Input Select 3D/2D Selection Signal Format Main Screen Subscreen PRESET 1 SIDE BY SIDE DVI-D 1 DVI-D 1 PRESET 2 SIDE BY SIDE DisplayPort SDI 1 PRESET 3 SIDE BY SIDE SDI 1 SDI 1 PRESET 4... -
Page 18: Pin Specifications
4-2. Pin Specifications ● DC IN terminal Pin No. Signal name 48 VDC 48 VDC ● DC OUT terminal on the main unit Pin No. Signal name 5 VDC 5 VDC HIROSE P/N: HR10A-7R-4S(74) Recommended plug HIROSE P/N: HR10A-7P-4P(74) ● DC OUT terminal of AC adapter Pin No. -
Page 19: Appendix
Apple, macOS, Mac OS, OS X, Macintosh and ColorSync are registered trademarks of Apple Inc. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. -
Page 20: Limited Warranty
The period of this Warranty is two (2) years from the date of purchase of the Product (hereinafter referred to as the “Warranty Period”). EIZO and Distributors shall bear no liability or obligation with regard to the Product in relation to the Original Purchaser or any third parties other than as provided under this Warranty. -
Page 21: Recycling Information
Este producto debe desecharse y reciclarse según la legislación del país para reducir el impacto medioambiental. Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una filial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. http://www.eizoglobal.com... - Page 22 Este produto, quando o deitar fora, deve ser recolhido e reciclado de acordo com a legislação do seu país para reduzir a poluição. Quando deitar fora este produto, contacte um distribuidor ou uma filial no seu país. Os endereços de contacto estão listados no website do EIZO, abaixo. http://www.eizoglobal.com...
- Page 23 страна за да се намали замърсяването на околната среда. Когато искате да се освободите от този продукт, моля свържете се с търговския му представител или със съответните органи отговарящи за това във вашата страна. Данните за връзка с нас са описани на следния Интернет сайт на EIZO: http://www.eizoglobal.com Informaţie referitoare la reciclare Acest produs, când debarasat, trebuie colectat şi reciclat conform legislaţiei ţării rspective ca să...
- Page 24 Geri Dönüşüm Bilgisi Bu ürünün, atılacağı zaman, ülkenizin çevre kirliliğinin azaltılması konusundaki mevzuatına göre toplanması ve yeniden değerlendirilmesi gerekmektedir. Ürünü atacağınız zaman lütfen ülkenizdeki bir distribütör veya ilgili kuruluşla temasa geçiniz. İrtibat adresleri aşağıdaki EIZO web sitesinde verilmiştir. http://www.eizoglobal.com Appendix...
- Page 25 03V27511A1 IM-EX31413D Copyright © 2018 EIZO Corporation. All rights reserved. 1st Edition-October, 2018...
