Installation Manual
Color LCD Monitor
Important
Please read this "Installation Manual", and "Instructions for Use"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• Refer to the "Instructions for Use" for information on the
installation / connection of the monitor.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CuratOR EX3242-3D and is the answer not in the manual?

Questions and answers

Related Manuals for Eizo CuratOR EX3242-3D

Summary of Contents for Eizo CuratOR EX3242-3D

  • Page 1 Installation Manual Color LCD Monitor Important Please read this “Installation Manual”, and “Instructions for Use” (separate volume) carefully to familiarize yourself with safe and effective usage. • Refer to the “Instructions for Use” for information on the installation / connection of the monitor.
  • Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO product specifications are subject to change without notice.

  • Page 3: Table Of Contents

    Contents Contents ..............3 Chapter 1 Basic Adjustment / Setting ....4 1-1. Loading the Monitor Settings ...... 4 ● Saving current settings to "User1" through "User5" ..........5 1-2. Switching Input Signals ....... 5 1-3. Using Custom Keys ........6 ●...

  • Page 4: Chapter 1 Basic Adjustment / Setting

    Chapter 1 Basic Adjustment / Setting This chapter describes the basic functions that can be adjusted and set by pressing the buttons on the front of the monitor. 1-1. Loading the Monitor Settings Basic settings are made in advance at the factory. It is possible to switch to the following preset settings that have been set in advance.

  • Page 5: Saving Current Settings To "User1" Through "User5

    ● Saving current settings to "User1" through "User5" You can save the current setting values and display status to "User1" through "User5". Press (MENU). The Setting menu appears. Press (F3) or (F4) to select "Preferences", and then press (ENTER). The "Preferences" menu appears. Press (F3) or (F4) to select "Preset Save", and then press...

  • Page 6: Using Custom Keys

    1-3. Using Custom Keys Execute the functions assigned to the custom keys (F1 ( ), F2 ( ), F3 ( ) and F4 ( )). For information on how to set a function to each custom key, see “Setting a function to custom keys” (page Press F1 ( ), F2 ( ), F3 (...

  • Page 7: Chapter 2 Advanced Adjustment / Setting

    Chapter 2 Advanced Adjustment / Setting This chapter describes advanced monitor adjustment and setting procedures using the main menu. 2-1. Basic Operation of the Setting Menu Menu display 1. Press (MENU). The Setting menu appears. Chapter 2Chapter Advanced Adjustment / Setting...
  • Page 8 Adjustment / Setting Pressing (MENU) during adjustment/setting will cancel the adjustment/setting and restore the state prior to making changes. 1. Press (F3) or (F4) to select a menu to adjust/set, and then press (ENTER). The submenu appears. 2. Press (F3) or (F4) to select an item to adjust/set, and then press (ENTER).

  • Page 9: Setting Menu Functions

    2-2. Setting Menu Functions ● Adjustments / settings for 3D display. Function Setting Description 3D/2D Selection Switches 3D/2D display. Note • Selecting "3D" will enable "Signal Format", "Left/ Right Swap", and "H Parallax". • Fixed at "2D" during PbyP display. Signal Format SIMUL Sets the signal format in 3D mode.

  • Page 10: Color Adjustment

    ● Color Adjustment Function Setting Description Active Window PbyP Left Window / Select which window to adjust settings when using dual screen Right Window display (PbyP or PinP). Disabled during single screen display. PinP Large Window / Note Small Window •...

  • Page 11: Signal

    ● Signal Function Setting Description Active Window (In single screen display mode.) Select which window to adjust settings in during dual screen display (PbyP or PinP). Disabled during single (When "Multi Window" is set to screen display. "PbyP") Left Window / Right Window (When "Multi Window"...

  • Page 12: Preferences

    ● Preferences Function Setting Description Multi Window Single / PbyP / PinP Select single screen display or dual screen display (PbyP or PinP). Disabled when "Display Direction" is "180°" or "Mirror" or "Signal format" is "TOP AND BOTTOM" or "SIDE BY SIDE" in 3D mode. •...
  • Page 13 Function Setting Description Custom Key [F1] Off / Backlight / Gamma Select the function that is assigned to each [F2] / Color Gamut / Multi custom key. For details, see “Setting a [F3] Window / Display function to custom keys” (page [F4] Direction / Swap Advanced...

  • Page 14: Information

    ● Information Display the monitor information (model name, serial number (S/N), usage time) and the input signal information. Example: Chapter 2Chapter Advanced Adjustment / Setting...

  • Page 15: Pbyp

    ● PbyP If you press (INPUT) while in PbyP dual screen mode, the "PbyP" menu is displayed. Function Setting Description Left Window DisplayPort / HDMI / SDI 1 / Select the signal input to the left window when PbyP dual screen SDI 2 / DVI display.

  • Page 16: Pinp

    ● PinP If you press (INPUT) while in PinP dual screen mode, the "PinP" menu is displayed. Function Setting Description Large Window DisplayPort / HDMI / SDI 1 / Select the signal input to the large window when PinP dual SDI 2 / DVI screen display.

  • Page 17: Chapter 3 Troubleshooting

    Chapter 3 Troubleshooting 3-1. No Picture Displayed Problem Possible cause and remedy 1. No picture. • Check whether the power cord is connected properly. • Check whether the DC OUT terminal and the DC IN terminal are connected properly. • Turn on the power switch. •...

  • Page 18: Imaging Problems

    3-2. Imaging Problems Problem Possible cause and remedy 1. The screen is too bright or too dark. • Use "Brightness" or "Backlight" in the Setting menu to adjust it. 2. Text is blurred • Check whether the computer is configured to meet the resolution and vertical scan frequency requirements of the monitor (see "Displayable Input Signals"...

  • Page 19: Chapter 4 Reference

    Chapter 4 Reference 4-1. Main Default Settings Preset Default DisplayPort HDMI [LINE Item [LINE BY DVI [2D] [SIMUL] BY LINE] LINE] MAIN DisplayPort SDI1 | SDI2 HDMI (Left Window / Large Window) Input Port DisplayPort (Right Window/Small Window) 3D/2D Selection Signal Format LINE BY LINE SIMUL...

  • Page 20: Pin Specifications

    4-2. Pin Specifications ● DC IN terminal Pin No. Signal name DC 48V DC 48V ● DC OUT terminal on the main unit Pin No. Signal name DC 5 V DC 5 V HIROSE P/N: HR10A-7R-4S(74) Recommended plug HIROSE P/N: HR10A-7P-4P(74) ●...

  • Page 21: Appendix

    United States and other countries. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorEdge Tablet Controller, ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO Monitor Configurator, EIZO ScreenSlicer, G-Ignition, i•Sound, Quick Color Match, RadiLight, Re/Vue, SafeGuard, Screen...

  • Page 22: Limited Warranty

    The period of this Warranty is three (3) years from the date of purchase of the Product (hereinafter referred to as the “Warranty Period”). EIZO and Distributors shall bear no liability or obligation with regard to the Product in relation to the Original Purchaser or any third parties other than as provided under this Warranty.
  • Page 23 03V29202B1 IM-EX32423D Copyright © 2022 EIZO Corporation. All rights reserved. 2nd Edition - November, 2022...
