- Page 1 Instruction for Use Full HD 27" LCD Monitor with DVI Input Module Important Please read the Safety Information and the information delivered with the product carefully to familiarize yourself with safe and effective usage.
-
Page 2: Legal Information
Note the following: WARNING EIZO products may only be used for the applications described in the catalog and in the relevant tech‐ nical documentation. If products and components from other manufacturers are used, these must be recommended or approved by EIZO. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems. -
Page 3: Table Of Contents
Display main menu ..................35 7.3.2 "Power Manager" main menu ..............36 7.3.3 "Other Options" main menu ............... 37 7.3.4 "Information" main menu................38 7.3.5 "Signal" main menu..................38 8 Cleaning and maintenance..................... 39 Cleaning ........................39 RadiForce EX270W Instruction for Use, 06/2014... - Page 4 13.2 Markings and symbols .................... 53 13.3 Environmental protection ..................54 13.4 Accessory devices ....................55 13.5 Contact........................55 13.6 Trademarks ......................56 13.7 China RoHS (Restriction of Hazardous Substances)..........57 Index ..........................59 RadiForce EX270W Instruction for Use, 06/2014...
-
Page 5: Introduction
Introduction Contents of this document This document explains the functionality and the approved use of the RadiForce EX270W. To ensure clarity, it does not contain all detailed information on this product. The contents of this document are neither part of a previous or existing agreement, commit‐... -
Page 6: Safety Instructions
General safety notes Correct transport, professional storage, installation and connection, as well as careful opera‐ tion and maintenance, are required to ensure that the EIZO devices operate safely and cor‐ rectly. The devices may only be used for applications for which they are commonly used. - Page 7 Touching the components may be fatal. No contact between device and patients The device is not suitable for direct contact with patients. Device and patient must never be touched simultaneously. Otherwise there is a danger to life and limb. RadiForce EX270W Instruction for Use, 06/2014...
- Page 8 Only use power cables approved for China. These power cables are identified by the labels "CCC" or "CQC". Observe the country-specific regulations Observe all regulations of the country in which the device is used. RadiForce EX270W Instruction for Use, 06/2014...
- Page 9 If the device is brought into a room with a higher or rising temperature, condensed water will form in and on the device. Do not switch on the device until the condensed water has evaporated. Otherwise the device could be damaged. RadiForce EX270W Instruction for Use, 06/2014...
- Page 10 Note that monitors can fail as a result of aging, and that image properties such as brightness, con‐ trast, and color value can change. Do not touch the monitor screen Due to mechanical pressure or electrostatic discharging, touching the screen can result in brief dis‐ turbances to the image. RadiForce EX270W Instruction for Use, 06/2014...
-
Page 11: Product-Specific Safety Information
Subsequent mounting of a stand If the monitor is subsequently mounted on a stand, the stand must meet the EN 60601 standard so that the system comprising the monitor and stand meets the EN 60601 stand‐ ard. RadiForce EX270W Instruction for Use, 06/2014... -
Page 12: Description
Note Keep the packaging material for subsequent transport of the device. Device The RadiForce EX270W is a LCD Monitor. The EX270W can be installed in a ceiling suspension or wall mount, a mobile medical sys‐ tem, or a stand. Product Order No. -
Page 13: Monitor Performance Features
Future monitor models and versions with different panel types, backlight properties, and transmission methods can be equipped and adapted for the application in question. New models are designed so that they can be integrated smoothly into existing linked systems with current monitors. RadiForce EX270W Instruction for Use, 06/2014... - Page 14 The device can be adapted specifically to the local installation, system, and bright‐ ness conditions, to be used for example in direct image reproduction, in the distributed video management network, or in the endoscopy tower. RadiForce EX270W Instruction for Use, 06/2014...
-
Page 15: Setup And Installation
CAUTION Changes to device Do not make any mechanical or electric changes to the device. EIZO GmbH will not be held liable if changes are made to the device. Installation site Note the following conditions at the installation location. NOTICE Device connections accessible at all times The monitor does not have a power switch. -
Page 16: Installing The Monitor
Comply with the manufacturer's specifications regarding strength and torque. • An installed stand must be sufficiently stable such that tilting up to 10° does not result in the monitor toppling. Comply with the manufacturer's specifications regarding strength and torque. RadiForce EX270W Instruction for Use, 06/2014... -
Page 17: Vesa Spacer And Vesa Positioning Rail
It can also be used to simplify the con‐ nection of the signal and power cables routed to the monitor. ① VESA spacer (from above) ② VESA spacer (from below) ③ Recesses ④ Holes with insert nuts (M4 threading) RadiForce EX270W Instruction for Use, 06/2014... -
Page 18: Installing The Vesa Spacer And Vesa Positioning Rail
VESA positioning rail are used to mount the monitor, the mechanical properties change. • Please note that when selecting and installing a system that you minimize the effect of vibration and shock when using the VESA forward spacer and/or VESA positioning rail. RadiForce EX270W Instruction for Use, 06/2014... - Page 19 1. Screw the four mounting screws approx. 3 mm deep into the monitor VESA attachment. 2. Place the VESA forward spacer in the orientation desired: – If movements in horizontal direction are planned, position the marking on the forward spacer to the left. RadiForce EX270W Instruction for Use, 06/2014...
- Page 20 The positioning rail has to turn accordingly when shifting to the left, right, up, or down. 4. Attach the VESA positioning rail to the VESA forward spacer using four mounting screws and a torque of 3 Nm. RadiForce EX270W Instruction for Use, 06/2014...
- Page 21 Setup and installation 4.2 Installing the monitor 5. Connect the ceiling suspension or wall mount to the threaded holes of the VESA posi‐ tioning rail. Comply with the information provided by the manufacturer. RadiForce EX270W Instruction for Use, 06/2014...
-
Page 22: Connecting
CAUTION Changes to device Do not make any mechanical or electric changes to the device. EIZO GmbH will not be held liable if changes are made to the device. CAUTION Shielding measures Follow all shielding measures according to the country-specific EMC Directive. If these guidelines are not observed, device malfunction may result. - Page 23 • Externally connected cables can represent a trip hazard. Make sure that all incoming cables are safely routed. • If the device includes cable grips, please use them to prevent unintended loosening of connected cables. RadiForce EX270W Instruction for Use, 06/2014...
-
Page 24: Device Connectors
⑥ VESA attachment DVI interface The Input module TRM0000-DVI provides the monitor with a DVI interface. See also Input module TRM0000-DVI 27]. Grounding screw The additional protective conductor is connected to the grounding screw. RadiForce EX270W Instruction for Use, 06/2014... -
Page 25: Power Connector
Description ① Input voltage 24 V +/- 10 % ② Ground ③ Used for service purposes ④ Used for service purposes ⑤ Used for service purposes Please note the following: RadiForce EX270W Instruction for Use, 06/2014... - Page 26 Molded power plugs must comply with the requirements for "hospital grade attachments" CSA Std. C22.2 No. 21 and UL 498. CAUTION Connection in China Only use power cables approved for China. These power cables are identified by the la‐ bels "CCC" or "CQC". RadiForce EX270W Instruction for Use, 06/2014...
-
Page 27: Input Module Trm0000-Dvi
NOTICE The picture quality, interference immunity, and emitted interference of the entire system depend on the cable quality and length. Use only the DVI cables specified by EIZO or the transmission links available from EIZO. NOTICE Video source settings The video source is set on the monitor using the EDID data transmitted via the DDC inter‐... - Page 28 3. Connect the external power supply to the monitor's M12 power connector ③. 4. Connect the external power supply's appliance plug to line power. Note: Comply with the information in section Power connector 25]. RadiForce EX270W Instruction for Use, 06/2014...
-
Page 29: Commissioning
Operation LED does not light green? If the operation LED does not light green after switching on and with a video signal ap‐ plied: • check the system for incorrect connection or operation before contacting Service. RadiForce EX270W Instruction for Use, 06/2014... -
Page 30: Avoidance Of Image Sticking
Operating a monitor with supported timing and resolution Note Supported timing The monitor supports timing from 50 Hz to 70 Hz. If the timing is not detected, either no image or a faulty image is displayed. RadiForce EX270W Instruction for Use, 06/2014... - Page 31 The corresponding firmware is installed on the Large Monitor Manager. NOTICE Installation and parameterization of the video source Please refer to the video source manufacturer’s manual for detailed information about in‐ stallation and configuration of the video source. RadiForce EX270W Instruction for Use, 06/2014...
-
Page 32: Operation
Enter ⑥ Standby/Operation ⑦ Operation LED Control keypad The RadiForce EX270W has a projective capacitive touch control keypad. The keys are lo‐ cated on the lower right corner on the front of the monitor. RadiForce EX270W Instruction for Use, 06/2014... -
Page 33: Locking Or Unlocking The Osd Menu
2. The press the "Down" key ③ three times. The LED display brightness changes when the keys are pressed as feedback. The OSD menu is now locked or unlocked, depending on its initial state. RadiForce EX270W Instruction for Use, 06/2014... -
Page 34: Description Of Osd Menu
Operation 7.3 Description of OSD menu Description of OSD menu The OSD menu is used to make settings for operation of the monitor. Fig. 1: OSD menu layout RadiForce EX270W Instruction for Use, 06/2014... -
Page 35: Display Main Menu
If you adjust brightness, the gray scale values no longer correspond to the set gamma curve. The calibrated values therefore cannot be guaranteed. Note: The brightness set significantly impacts the operating life of the backlight. RadiForce EX270W Instruction for Use, 06/2014... -
Page 36: Power Manager" Main Menu
"Backlight Dim‐ med". Prior to diagnosing radiographic images however, the lamp requires a warm-up time after reactivation. • Disabled: DMPM signals are ignored. The monitor does not change to energy saving mode. RadiForce EX270W Instruction for Use, 06/2014... -
Page 37: Other Options" Main Menu
"Execute Reset". Note: All changes or recalibrations made are lost when resetting back to the factory set‐ tings. If you are uncertain, contact your serv‐ ice partner. RadiForce EX270W Instruction for Use, 06/2014... -
Page 38: Information" Main Menu
Adjustment / setting Description range Information Input Width #### Selecting this function displays information regarding the video signal at the video input. Height #### The input shows which module is used on the video input. RadiForce EX270W Instruction for Use, 06/2014... -
Page 39: Cleaning And Maintenance
Fairy Ultra, Pril, Palmolive liquid Pyridine derivatives Activ spray, undiluted Water Tap water Distilled water Note Information on cleaning or disinfection of other system components can be obtained from the respective instructions for use. RadiForce EX270W Instruction for Use, 06/2014... -
Page 40: Maintenance
• SMPTE pattern: The gray levels must be displayed correctly and visibly at both 5% and 95%. • VeriLum pattern: The small squares must be visibly displayed in all gray scale levels. RadiForce EX270W Instruction for Use, 06/2014... -
Page 41: Troubleshooting
The monitor is in a warm-up period. • Select a lower brightness level for standard operation. • Wait for the warm-up period to expire. The LED turns green when the stable luminance level is reached. RadiForce EX270W Instruction for Use, 06/2014... - Page 42 Select a lower brightness level for standard temperature and avoid potential dam‐ operation. age. Internal error • Inform Service. Dark LED timeout activated • No error. • Switch off the LED timeout setting. Operation LED is defective • Inform Service. RadiForce EX270W Instruction for Use, 06/2014...
-
Page 43: Technical Specifications
External M12 power supply unit (included in scope of delivery) Power connector Non-heating appliance socket Line voltage (input) 100 V AC - 240 V (± 10 %) Line frequency 50 Hz - 60 Hz (± 5 %) RadiForce EX270W Instruction for Use, 06/2014... -
Page 44: Input Modules
Input module TRM0000-TDL • 1 single link DVI connection signal via RJ45 socket - max. 1920 x 1080 at 50 - 70 Hz • Service and communication using DDC chan‐ nel of RJ45 socket RadiForce EX270W Instruction for Use, 06/2014... -
Page 45: Mechanical Design
Transport and storage (packed) Temperature range -20 °C - +60 °C ambient temperature Temperature gradient Max. 5 °C/h, no condensation Humidity 10 - 90 %, non condensing, at 25 °C Air pressure 200 - 1060 hPa RadiForce EX270W Instruction for Use, 06/2014... -
Page 46: Safety Regulations
(10 - 200 Hz) at 1 m²/s³ (200 - 2000 Hz) at 0.3 m²/s³ 60 minutes per x/y/z axis Shock According to EN 60068-2-27 100 m/s², 11 ms, vertical axis, 100 shocks each in + and - direction RadiForce EX270W Instruction for Use, 06/2014... -
Page 47: Electromagnetic Compatibility
Testing with 100 V/60 Hz and 240 V/50 Hz nomi‐ nal voltage 2, 3 kV, 5/50 nsec; coupling to power supply ca‐ bles, ±2 kV to signal cables Burst on signal lines EN 61000-4-4:2010-03 1 kV RadiForce EX270W Instruction for Use, 06/2014... - Page 48 Nominal voltage 240 V/50 Hz (-30 %); measure‐ ment according to Class D GB17625.1 Line reaction to voltage fluctuations EN 61000-3-3 Ed.2.0 (2008-06) EN 61000-3-3 Edition 2008-09 Nominal voltage 240 V/50 Hz (-30 %) RadiForce EX270W Instruction for Use, 06/2014...
-
Page 49: Dimensioned Drawings
Dimensioned drawings 11.1 Front view Dimensioned drawings All dimensions in mm 11.1 Front view RadiForce EX270W Instruction for Use, 06/2014... -
Page 50: View From Behind, Below, And To The Side - With Dvi Input Module
Dimensioned drawings 11.2 View from behind, below, and to the side - with DVI input module 11.2 View from behind, below, and to the side - with DVI input module RadiForce EX270W Instruction for Use, 06/2014... -
Page 51: Spare Parts / Accessories
EX270W. It can be ordered later as needed. Order no.: 6GF6278-0LA00 M12 power cable extension The M12 power cable extension, with a length of 15 m, enables split installation of the exter‐ nal power supply. Order no.: 6GF6278-0LA01 RadiForce EX270W Instruction for Use, 06/2014... - Page 52 Together with the Input module TRM0000-M12, the TDL M12 cable offers the highest IP protection rating for the EX270W monitor. The TDL signal cables can be combined with other EIZO products (LMM0804, TDL trans‐ mitter, etc.), and can be connected to the EX270W input module directly or via an adapter.
-
Page 53: Appendix
Appendix 13.1 Guidance and manufacturer's declaration – electromagnetic emissions The RadiForce EX270W monitor is intended for use in the environment specified below. The user of the monitor should ensure that it is used in such an environment. Emissions test Compliance Electromagnetic environment –... -
Page 54: Environmental Protection
Symbol for equipotential bonding (device) Symbol "Comply with the instructions for use". (device) EX270W name plate Name plate Input module TRM0000-DVI 13.3 Environmental protection Please observe all local requirements and laws pertaining to the disposal of devices. RadiForce EX270W Instruction for Use, 06/2014... -
Page 55: Accessory Devices
Appendix 13.4 Accessory devices 13.4 Accessory devices Connected devices such as PCs must meet the relevant safety standards. 13.5 Contact Support during installation and for technical questions Medical Solutions (http://www.eizo.com) RadiForce EX270W Instruction for Use, 06/2014... -
Page 56: Trademarks
13.6 Trademarks EIZO Logo is a registered trademark of EIZO Corporation in Japan and other countries. EIZO is a registered trademark of EIZO Corporation in Japan and other countries. RadiForce is a registered trademark of EIZO Corporation in Japan and other countries. -
Page 57: China Rohs (Restriction Of Hazardous Substances)
13.7 China RoHS (Restriction of Hazardous Substances) 13.7 China RoHS (Restriction of Hazardous Substances) 液晶显示器 LCD Monitor 型号 Model: RadiForce EX270W 根据 SJ/T11364-2006《电子信息产品污染控制标识要求》特提供如下有关污染控制方面的信 息。 The following product pollution control information is provided according to SJ/T11364-2006 Marking for Control of Pollution caused by Electronic Information Products. - Page 58 Applications of hazardous substances in this medical device are required to achieve its intended clinical uses, and/or to provide better protection to human beings and/or to environment, due to lack of reasonably (economically or technically) available substitutes. 产品中有毒有害物质或元素的名称及含量 Table of hazardous substances’ name and con‐ centration. RadiForce EX270W Instruction for Use, 06/2014...
-
Page 59: Index
Orientation Environment OSD menu Equipotential bonding connector Lock/unlock Fully Automated Stability Personnel Pixel defects Positioning rail Power connector General safety notes Grounding measure Grounding screw Quality test Image Sticking Input module Versions Installation Keys RadiForce EX270W Instruction for Use, 06/2014... - Page 60 Index Safety regulations Screen brightness Service Service personnel Shielding measures Spacer Spare parts Standby Switch on Technical specifications Timing Troubleshooting User VESA positioning rail VESA spacer Video source Zero error rate RadiForce EX270W Instruction for Use, 06/2014...
- Page 62 Siemensallee 84 76187 Karlsruhe Germany Instruction for Use, 06/2014 RadiForce EX270W 1051368-001 Copyright © 2014 EIZO GmbH. All rights reserved.
