Instructions for Use
Color LCD monitor
Important
Please read this "Instructions for Use", and "Installation Manual"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
• For monitor adjustment and settings, refer to the Installation Manual.
• The latest "Instructions for Use" is available for download from our
web site :
http://www.eizoglobal.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eizo CuratOR EX2620-3D
Summary of Contents for Eizo CuratOR EX2620-3D
- Page 1 Instructions for Use Color LCD monitor Important Please read this “Instructions for Use”, and “Installation Manual” (separate volume) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For monitor adjustment and settings, refer to the Installation Manual. •...
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Important
PRECAUTIONS ● IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • To personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor. - Page 4 If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
- Page 5 WARNING Use the enclosed AC adaptor. The enclosed AC adapter (AHM100PS24) is for use with this product only. Do not use the AC adapter with other equipment. Do not use an AC adapter designed for other devices with this product. Connecting to power sources that do not match the power ratings of the AC adapter may result in fire or electric shock.
- Page 6 CAUTION Check the operational state before use. • Begin use after ensuring that there are no problems with the displayed image. • When using multiple units, begin use after ensuring that the images are displayed appropriately. • When viewing 3D images, use 3D Polarized Eyewear, and ensure that the environmental requirements for viewing 3D images are satisfied.
- Page 7 CAUTION Periodically clean the area around the power plug and the ventilation slot of the monitor and the AC adapter. Dust, water, or oil on the plug may result in fire. Unplug the unit before cleaning it. Cleaning the unit while it is plugged into a power outlet may result in electric shock. If you plan to leave the unit unused for an extended period of time, disconnect the power cord from the wall socket after turning off the power switch for the safety and the power conservation.
-
Page 8: Notice For This Monitor
• The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • The screen may have defective pixels or a small number of light dots on the screen. This is due to the characteristics of the panel itself, and is not a malfunction of the product. -
Page 9: Cleaning
Cleaning Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. Gently wipe off any dirt on the cabinet or panel surface with a soft cloth soaked in a small amount of water or one of the chemicals listed below. Chemicals that may be used for cleaning Material name Product name... -
Page 10: Table Of Contents
CONTENTS PRECAUTIONS ............3 ● IMPORTANT ........... 3 Notice for this monitor ......... 8 Intended use ............. 8 Precautions for Use ..........8 Cleaning ..............9 To use the monitor comfortably ......9 CONTENTS ............10 Chapter 1 Introduction ........11 1-1. -
Page 11: Chapter 1 Introduction
Chapter 1 Introduction 1-1. Features ● High-quality and high-resolution Full HD LCD panel • The IPS panel enables high-resolution, high-quality medical images to be displayed. • Front protection panel fitted • LED Backlight • Optical bonding for high visibility ● Supporting 3D display •... -
Page 12: Package Contents
1-2. Package Contents Check that all of the following items are contained in the package. Note • It is recommended that the box and packing materials be stored so that they can be used to move or transport this product. •... - Page 13 Front Bottom View Displays the preset menu. (PRESET) button Displays the input select menu. (INPUT) button Displays the main menu. (MENU) button Executes the function assigned to this button. Select items in the menu screen. (F1) button (F2) button (F3) button (F4) button Switches the 3D and 2D displays.
- Page 14 Rear 25 26 11. DC IN terminal Connects the DC OUT terminal of the AC adapter. 12. VIDEO input terminal Connects devices having Composite video output terminals. (BNC type) 13. Y/G input terminal Connects devices having Y (luminance) for component output, or devices having G (BNC type) for RGB component.
- Page 15 Rear (Continued) 25 26 22. DC OUT terminal Used to supply 5V power to a peripheral. Attention • No device making contact with a patient may be connected to the DC OUT terminal. 23. VIDEO input terminal The signal input to VIDEO input terminal is output as is. (BNC type) 24.
-
Page 16: Chapter 2 Installation / Connection
Chapter 2 Installation / Connection 2-1. Before Installing the Product Carefully read “PRECAUTIONS” (page 3) and always follow the instructions. When introducing this product, execute thorough operational testing (of the system, cables, arms, etc.) in the environment where the product will be used. ●... -
Page 17: Installing The Product
2-2. Installing the Product This product should be installed using an arm or stand. Attention • When installing, do so by carefully following the information in the User’s Manual about the arm or stand. • Ensure the following and select components that comply with the VESA standards. - Clearance between the screw holes: 100 mm ×... -
Page 18: Connecting The Power Cord
2-3. Connecting the Power Cord Attention • Turn off the monitor before connecting it. • When removing the power cord, always remove the power plug from the power outlet first. Connect the power cord to the AC IN terminal on the AC adapter. Insert the power cord all the way to the back. -
Page 19: Connecting The Cables
2-4. Connecting the Cables Connect the cables appropriate for the device to be used. Attention • Do not use damaged cables. • Do not connect or disconnect the signal cable while the monitor is turned on. • The terminal parts of the SDI terminal and DVI-D terminal are vulnerable to static electricity, so be sure to work with care at installation.When working with the monitor, be sure to observe the following. -
Page 20: Installing The Cable Cover
2-5. Installing the Cable Cover Align the cable cover on the back of the monitor in such a way that the cables can go through the cable outlet port. Insert the cable cover tabs into the grooves in the monitor. Tighten the screws at the left and right holes on the bottom side of the monitor. -
Page 21: Chapter 3 If No Image Is Displayed
Chapter 3 If No Image Is Displayed Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Power indicator does not light up. • Check whether the DC OUT terminal and the DC IN terminal are connected properly. -
Page 22: Chapter 4 Specifications
Chapter 4 Specifications 4-1. Specifications List Monitor LCD Panel Type Color (IPS) Backlight Size 66.1 cm (26 inch) Resolution (H x V) 1920 × 1080 Display Size (H x V) 576 mm × 324 mm Pixel Pitch 0.3 mm Display Colors 8-bit: 16.77 million colors 10-bit (SDI only): 1073.74 million colors (Max.) Viewing Angles... - Page 23 Operating Environmental Requirements Temperature 0 ˚C to 35 ˚C (32 ˚F to 95 ˚F) Humidity 20 % to 85 % R.H. (no condensation) Air Pressure 540 hPa - 1060 hPa Transportation / Storage Environmental Requirements Temperature -20 ˚C to 60 ˚C (-4 ˚F to 140 ˚F) Humidity 10 % to 90 % R.H.
-
Page 24: Displayable Input Signals (2D)
4-2. Displayable Input Signals (2D) √: Supported RGB / RGB / YP Horizontal Vertical VIDEO SDI 1 DVI 1 HD15 Signal name Frequency Frequency S VIDEO SDI 2 RGB-VIDEO RGB-PC DVI 2 (kHz) (Hz) mode mode mode NTSC 15.734 59.940 √... -
Page 25: Displayable Input Signals (3D)
Attention • Input Sync on Green or composite Sync (VBS) as sync signal into the RGB input terminal. Some PCs cannot display images. Note • The input signal above is a displayable input signal when using a single product without connecting an output. 4-3. -
Page 26: Appendix
Appendix Medical Standard • It shall be assured that the final system is in compliance to IEC60601-1-1 requirement. • Power supplied equipment can emit electromagnetic waves, that could influence, limit or result in malfunction of the monitor. Install the equipment in a controlled environment, where such effects are avoided. -
Page 27: Emc Information
EMC Information The EX2620-3D has a performance that appropriately displays images. Environments of Intended Use The EX2620-3D is intended to be used in Professional healthcare facility environments such as clinics and hospitals (including use in the vicinity of high-frequency surgical equipment such as electrosurgical knives). - Page 28 Technical Descriptions Electromagnetic emissions The EX2620-3D is intended for use in the electromagnetic environment specified below. The customer or the user of the EX2620-3D should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment - Guidance RF emissions Group 1 The EX2620-3D uses RF energy only for its internal function.
- Page 29 Electromagnetic immunity The EX2620-3D has been tested at the following compliance levels according to the testing requirements for professional healthcare facility environments defined in IEC / EN60601-1-2. Customers and users of the EX2620-3D must ensure that the EX2620-3D is used in the following environments: Immunity test Test level for professional Compliance level...
- Page 30 Recommended separation distances between portable or mobile RF communication equipment and the EX2620-3D The EX2620-3D is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the EX2620-3D can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the EX2620-3D.
-
Page 31: Warning For Radio Interference
Warning for Radio interference For U.S.A, Canada Only WARNING! This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 32 153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan 中国苏州市苏州工业园区展业路 8 号中新科技工业坊 5B Siemensallee 84, 76187 Karlsruhe, Germany 00N0N007A1 http://www.eizoglobal.com IFU-EX26203D-6 Copyright © 2017 EIZO Corporation. All rights reserved. 1st Edition-June, 2017 Printed in Japan.
