Instructions for Use
Color LCD Monitor
Important
Please read this "Instructions for Use", and "Installation Manual"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• For monitor adjustment and settings, refer to the "Installation
Manual". The "Installation Manual" is part of the "Instructions for
Use".
Advertisement
Table of Contents
Related Manuals for Eizo CuratOR EX5542
Summary of Contents for Eizo CuratOR EX5542
- Page 1 Instructions for Use Color LCD Monitor Important Please read this “Instructions for Use”, and “Installation Manual” (separate volume) carefully to familiarize yourself with safe and effective usage. • For monitor adjustment and settings, refer to the “Installation Manual”. The “Installation Manual” is part of the “Instructions for Use”.
- Page 2 EIZO GmbH. EIZO GmbH is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO GmbH’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO product specifications are subject to change without notice.
-
Page 3: Precautions
PRECAUTIONS IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • To ensure personal safety and proper maintenance, please read carefully this section. PRECAUTIONS... - Page 4 Markings and symbols Symbol This symbol indicates Power Switch: Press to turn the monitor’s power off. Power Switch: Press to turn the monitor’s power on. Alternating current Dangerous voltage CAUTION: Refer to “SAFETY SYMBOLS” (page Protective earth (grounding terminal) Potential equalization terminal Product must be disposed of separately;...
- Page 5 If the unit is installed incorrectly, it may drop or fall over, resulting in personal injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
- Page 6 WARNING Use the correct voltage. • The unit is designed for use with a specific voltage only. Connection to a voltage other than that specified in this “Instructions for Use” may cause fire, electric shock, or equipment damage. Power supply: 100-240Vac 50/60Hz •...
- Page 7 CAUTION Check the operational state before use. • Begin use after ensuring that there are no problems with the displayed image. • When using multiple units, begin use after ensuring that the images are displayed appropriately. Securely fix cables / cords that have a fixing feature. If they are not fixed securely, cables / cords may disconnect, and subsequently images may be cut off and your operations may be disrupted.
-
Page 8: About The Monitor
About the Monitor Intended use Intended purpose The EX4942 / EX5542 is intended for the display of still images and moving images from various commercially available devices commonly used in a medical environment, in particular endoscopic.The monitor is optimized for the reproduction of colour images. The monitor is not suitable for mammography. Intended patient population and medical conditions The monitor can be used for the intended purpose irrespective of age, body weight and gender. -
Page 9: Precautions For Use
• The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on the LCD panel, this is not a malfunction. -
Page 10: Cleaning
Cleaning Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. Gently wipe off any dirt on the cabinet or panel surface with a soft cloth soaked in a small amount of water or one of the cleaning agents and disinfectants listed below. Recommended cleaning agents and disinfectants Tested cleaning agents and Agent class... -
Page 11: Table Of Contents
CONTENTS PRECAUTIONS ............3 IMPORTANT .............. 3 About the Monitor ..........8 Intended use ............. 8 Precautions for Use ..........9 Cleaning ..............10 CONTENTS ............11 Chapter 1 Introduction ........12 1-1. Features ............12 1-2. Package Contents ........13 1-3. Controls and Functions ......13 Chapter 2 Installation / Connection .... -
Page 12: Chapter 1 Introduction
Chapter 1 Introduction 1-1. Features ● High-quality and high-resolution Ultra High Definition (UHD) • The UHD LCD display allows for display of high-quality, high-resolution medical images. • Equipped with front protection panel • LED Backlight • High luminosity ● Supports multiple I/O •... -
Page 13: Package Contents
1-2. Package Contents Check that all of the following items are included in the package. Note • It is recommended that the box and packing materials be stored so that they can be used to move or transport this product. •... - Page 14 Rear 10. Equipotential terminal The equipotential terminal is used when electric potential between electric devices differs and therefore needs to be equalized. This prevents differences in the potential between devices and conductive parts and minimizes the ground resistance. The equipotential bonding connection on the device can minimize contact voltages from different sources, for example, when the device is used in a system with other devices.
-
Page 15: Chapter 2 Installation / Connection
Chapter 2 Installation / Connection 2-1. Before Installing the Product Carefully read “PRECAUTIONS” (page 3) and always follow the instructions. When installing this product, perform thorough operational testing (of the system, cables, arms, etc.) in the environment where the product will be used. ●... -
Page 16: Installing The Product
2-2. Installing the Product This product should be installed using an arm or stand. Attention • Installation and commissioning may be performed by appropriately trained skilled personnel only. • When installing, do so by carefully following the information in the User Manual about the arm or stand. •... -
Page 17: Connecting The Cables
2-3. Connecting the Cables Plug the power connector on the monitor and the power cord into a power outlet. Insert the power cord fully into the monitor. Connect the cables appropriate for the device to be used. If you connected the HDMI cable to the monitor, be sure to secure the HDMI cable with the HDMI cable holder. -
Page 18: Installing The Cable Cover
2-4. Installing the Cable Cover Align the cable cover on the back of the monitor in such a way that the cables can go through the cable outlet port. Insert the cable cover tabs into the grooves in the monitor. Tighten the screws at the left and right-hand holes on the back side of the monitor. -
Page 19: Chapter 3 If No Image Is Displayed
Chapter 3 If No Image Is Displayed Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Turn on the power switch. • Turn off the power, and then turn it on again. 2. -
Page 20: Chapter 4 Specifications
Chapter 4 Specifications 4-1. Specifications List Monitor LCD Panel Type Color (IPS) Backlight Size EX4942: 124.5 cm (49 inch) EX5542: 139.7 cm (55 inch) Display resolution (H x V) 3840 × 2160 Display Size (H x V) EX4942 : 1097.2 mm × 630.0 mm EX5542 : 1233.4 mm ×... -
Page 21: Displayable Input Signals
4-2. Displayable Input Signals P : Supported -: Not Supported Vertical Scan Resolution Scan Format DisplayPort HDMI DVI-D Frequency (Hz) 640 × 480 Progressive 59.940 800 × 600 Progressive 60.317 1024 × 768 Progressive 60.004 1280 × 800 Progressive 59.810 1280 ×... -
Page 22: Appendix
Appendix Medical Standard • Anyone who connects additional equipment to the signal input parts or signal output parts when configuring a medical system is responsible for ensuring that the system complies with the requirements of IEC/EN60601-1. • Power-supplied equipment can emit electromagnetic waves that could influence, limit or result in malfunction of the monitor. -
Page 23: Emc Information
EMC Information The performance of the EX4942 / EX5542 ensures appropriate display of images. Intended Use Environments The EX4942 / EX5542 is intended to be used in professional healthcare facility environments such as clinics and hospitals (including use in the vicinity of high-frequency surgical equipment such as electrosurgical knives). - Page 24 Technical Specifications Electromagnetic emissions The EX4942 / EX5542 is intended for use in the electromagnetic environment specified below. The customer or the user of the EX4942 / EX5542 should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment - Guidance RF emissions...
- Page 25 Electromagnetic immunity The EX4942 / EX5542 has been tested at the following compliance levels according to the testing requirements for professional healthcare facility environments defined in IEC / EN60601-1-2. Customers and users of the EX4942 / EX5542 must ensure that the EX4942 / EX5542 is used in the following environments: Immunity test Test level for...
- Page 26 Recommended separation distances between portable or mobile RF communication equipment and the EX4942 / EX5542 The EX4942 / EX5542 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the EX4942 / EX5542 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the EX4942 / EX5542.
- Page 27 The EX4942 / EX5542 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. For other portable and mobile RF communication equipment (transmitters), the minimum distance between portable and mobile RF communications equipment (transmitters) and the EX4942 / EX5542 should be according to the maximum output power of the communication equipment as recommended below.
-
Page 28: Warning For Radio Interference
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord... -
Page 29: 中国在 Chinarohs 中为 Rohs 合规性采取的措施
中国在 ChinaRoHS 中为 RoHS 合规性采取的措施 关于电器电子产品有害物质限制使用标识 本标识根据 「电器电子产品有害物质限制使用管理办法」 ，适用于在中华人民共和国销售的电器电子 产品。标识中央的数字为环保使用期限的年数。只要您遵守该产品相关的安全及使用注意事项，在 自制造日起算的年限内，不会产生对环境污染或人体及财产的影响。上述标识粘贴在机器背面。 下表是依据 SJ/T 11364-2014 的规定编制。 产品中有害物质的名称及含量 部件名称 有害物质 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 （Pb） （Hg） （Cd） （Cr （ VI） ） （PBB） （PBDE） 印刷电路板 〇 〇 〇 〇 〇 〇 机箱... - Page 30 保証 保証規定 1. この製品の取扱説明書、本体添付ラベルなどの注意書に従った使用状態で保証期間内に故障した場合、無償で故障箇所の修理ま たは交換をいたします。お買い上げの販売店またはEIZOメンテナンスセンターにお申しつけください。 2. 保証期間内でも次のような場合には、有償となります。 ● 使用上の誤り、または不当な修理や改造による故障および損傷 ● お買い上げの後の輸送・移動・落下などによる故障および損傷 ● 火災・地震・水害・落雷・その他の天災地変ならびに公害や異常電圧などの外部要因や、塵・埃に起因する故障および損傷 ● 強い振動や衝撃を受ける場所に搭載された場合に生じる故障および損傷 ● 当社が想定する使用環境や使用状況を逸脱した場合 ● 電池の液漏れによる故障及び損傷 ● 液晶パネル、バックライトの経年劣化（輝度の変化、色の変化、輝度と色の均一性の変化、焼き付き、欠点の増加など） ● センサー経年変化による性能劣化（測定値の変化など） ● 外装品（液晶パネルの表面を含む）の損傷、変色、劣化 ● 付属品（ケーブル、取扱説明書、CD-ROM など）の故障、損傷、劣化、紛失 ● 当社指定の消耗品（電池、リモコン、タッチペンなど）の故障、損傷、劣化、紛失 ● 塵・埃などの外的要因による冷却ファンの異音、回転不良 ● 技術革新などにより製品に互換性がなくなった場合 3. 修理の際に当社の品質基準に達した再生部品を使用することがあります。 4. 修理状況や補修用性能部品の在庫切れなどにより修理できない場合は、修理に代えて同等性能製品への置き換えを提案させてい ただくことがあります。 5. 当社は、この製品の使用または故障により生じた直接、間接（逸失利益などを含む）のいかなる損害について責任を負いませ ん。また、この製品の記憶装置に記録された内容の消失などについても同様です。 6. 当保証規定は日本国内においてのみ有効です。 This warranty is valid only in Japan. Appendix...
-
Page 31: アフターサービス
