Tridonic EM converterLED ST Product Manual

Led driver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LED Driver
EM converterLED ST
Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EM converterLED ST and is the answer not in the manual?

Questions and answers

Related Manuals for Tridonic EM converterLED ST

Summary of Contents for Tridonic EM converterLED ST

  • Page 1 LED Driver EM converterLED ST Product Manual...

  • Page 2: Table Of Contents

    Product manual EM converterLED ST | 08-2018 | 1.0 | en Table of Contents Scope of documentation 4 Validity ........................4 Copyright .
  • Page 3 Product manual EM converterLED ST | 08-2018 | 1.0 | en Table of Contents Installation notes 35 Safety information ......................35 Routing the wires .

  • Page 4: Scope Of Documentation

    The series comprises additional versions. However, the other versions EM converterLED PRO and EM converterLED BASIC are not covered within this documentation. TRIDONIC GmbH & Co KG is constantly striving to improve all its products. This means that there may be changes in shape, features and technology.

  • Page 5: Safety Instructions

    The instructions in this section have been compiled to ensure that operators and users of combined emergency lighting LED Drivers of the EM converterLED ST series from Tridonic are able to detect potential risks in good time and take the necessary preventative measures.

  • Page 6: Additional Instructions

    Product manual EM converterLED ST | 08-2018 | 1.0 | en Safety instructions 2.4. Additional instructions ½ CAUTION! Electromagnetic compatibility (EMC) Although the device meets the stringent requirements of the appropriate directives and standards on electromagnetic compatibility, it could potentially interfere with other devices under certain circumstances!

  • Page 7: Introduction

    Thanks to power control in emergency operation, the slim, transparent range of the EM converterLED product group offers utmost flexibility for a number of combinations of LED light sources with LED Drivers by Tridonic and other renowned manufacturers. As an LED Driver for non-maintained mode, EM converterLED is used in combination with standard and dimmable LED Drivers. It is available as SELV and Non-SELV versions and with different functions.

  • Page 8: Portfolio Of Products

    For installations inside the luminaire Typical area of application: Spotlights, downlights Dimensions: 179 × 30 × 21 mm 4.2. Forward voltage The EM converterLED ST is available with three different forward voltages: 10-52 V, 40-97 V, 50-200 V 8 / 38...

  • Page 9: Functions In Emergency Operation

    Product manual EM converterLED ST | 08-2018 | 1.0 | en Functions in emergency operation Overview of the main functions in emergency operation: Area Function Automatic function and duration test Test activation via Test function, p. 19 selftest Function test (interval)

  • Page 10: Adjustable Output Current

    5.1.1. Description If the EM converterLED ST switches to emergency operation in case of a power failure, the device will detect the forward voltage of the connected LED modules and set the correct LED current. Setting a constant output power ensures maximum light output in emergency mode for the specified operating time.
  • Page 11 Product manual EM converterLED ST | 08-2018 | 1.0 | en Functions in emergency operation 5.1.2. Calculation Formel: P = U * I LED forward voltage: LED forward current: Emergency output power: Detected by the EM converterLED Automatically adjusted by the EM...
  • Page 12 Product manual EM converterLED ST | 08-2018 | 1.0 | en Functions in emergency operation EM converterLED ST 105 90V 40-97 V SELV < 120 V 5 cells for light output in emergency operation EM converterLED ST 105 NiMH 40-97 V SELV <...

  • Page 13: Intelligent Multilevel Charging System

    Shorter charge time after only a partial discharge. When the permanent power supply is switched on for the first time the EM converterLED ST starts to charge the batteries for 20 hours in fast charge mode. This 20-hour preparatory charge ensures that the new batteries are completely charged before being used.

  • Page 14: Rest Mode, Inhibit Mode And Relight Command

    Product manual EM converterLED ST | 08-2018 | 1.0 | en Functions in emergency operation 5.3. Rest mode, Inhibit mode and Relight command Emergency operation is automatically started when the mains supply is switched off. If the Rest mode is activated, the discharging of the battery will be minimized by switching off the LED output.
  • Page 15 Product manual EM converterLED ST | 08-2018 | 1.0 | en Functions in emergency operation Apply DC voltage pulse at the two terminal points "REST/L" and "REST/N" The signal must have an amplitude 9.5 - 22.5 V with a pulse length of 1,001 - 2,000 ms...
  • Page 16 Product manual EM converterLED ST | 08-2018 | 1.0 | en Functions in emergency operation Apply DC voltage pulse at the two terminal points "REST/L" and "REST/N" The signal must have an amplitude 9.5 - 22.5 V with a pulse length of 1,001 - 2,000 ms The polarity of the voltage pulse does not matter 5.3.7.

  • Page 17: Indicator Led

    Product manual EM converterLED ST | 08-2018 | 1.0 | en Functions in emergency operation 5.4. Indicator LED System status is locally indicated by a bi-colour indicator LED. LED indication Status Description Permanent GREEN Standby, System OK Mains operation, battery is charged...
  • Page 18 Product manual EM converterLED ST | 08-2018 | 1.0 | en Functions in emergency operation Slow flashing RED Battery failure Battery failed duration test or function test -or- Battery is defect -or- Incorrect (1 s on - 1 s off)

  • Page 19: Settings For Emergency Tests

    Product manual EM converterLED ST | 08-2018 | 1.0 | en Settings for emergency tests Annotation: (1) First connection to the power supply (2) Phase, in which the power supply is switched on and off (possibly numerous times) (3) Phase, in which the power supply is "permanently" connected (no interruption for at least 5 days)

  • Page 20: Test Times And Test Intervals

    The commissioning test is often made more difficult because the power supply is switched on and off during the installation phase. This is the case, for example, if the site is powered off at night for security reasons. To address this problem, the EM converterLED ST monitors the power supply and will only start with the commissioning test if the power supply hasn't been interrupted for 5 days.

  • Page 21: Weekly Function Test

    NOTICE If the power supply is interrupted, the information in the EM converterLED ST is stored for at least one week. If the power supply is interrupted for more than one week, the EM converterLED ST will perform another commissioning test when the power supply returns (after 20 hours initial charge mode).

  • Page 22: Annual Duration Test

    22 NOTICE If the power supply is interrupted during battery replacement, the EM converterLED ST loses its memory contents. When the power supply returns, the EM converterLED ST will perform another commissioning test (after 20 hours initial charge mode) 6.5.
  • Page 23 Product manual EM converterLED ST | 08-2018 | 1.0 | en Settings for emergency tests NOTICE The test switch can remain permanently connected and used as a startup tool. 6.6.1. Starting the function test A short press on the button (0.15 - 1 s) starts a function test lasting 5 seconds.

  • Page 24: Determining Light Output In Emergency Operation

    Light output in emergency operation 7.1. Parameter 1: LED forward voltage The total forward voltage of all connected LED modules must be within the forward voltage range of the EM converterLED ST 7.1.1. Total forward voltage of all LED modules The forward voltage of a single LED module can be found in the data sheet.
  • Page 25 Product manual EM converterLED ST | 08-2018 | 1.0 | en Determining light output in emergency operation 7.1.2. Example 1: 1 LED module DLE Given: Forward voltage DLE: 24.2 V (taken from data sheet) Wanted: Total forward voltage of all LED modules in emergency operation...
  • Page 26 Product manual EM converterLED ST | 08-2018 | 1.0 | en Determining light output in emergency operation 7.1.3. Example 2: 2 LED module DLE in parallel Given: Forward voltage DLE: 24.2 V (taken from data sheet) Wanted: Total forward voltage of all LED modules?

  • Page 27: Parameter 2: Led Current

    Determining light output in emergency operation 7.2. Parameter 2: LED current Each EM converterLED ST has a specific current/voltage characteristic. The corresponding current/voltage curve can be found in the datasheet: EM converterLED ST 103 50V / EM converterLED ST 103 NiMH 50V...
  • Page 28 Product manual EM converterLED ST | 08-2018 | 1.0 | en Determining light output in emergency operation EM converterLED ST 134 NiCd 50V EM converterLED ST 104 90V / EM converterLED ST 104 NiMH 90V 28 / 38...
  • Page 29 Product manual EM converterLED ST | 08-2018 | 1.0 | en Determining light output in emergency operation EM converterLED ST 105 90V / EM converterLED ST 105 NiMH 90V EM converterLED ST 104 200V / EM converterLED ST 104 NiMH 200V...
  • Page 30 Product manual EM converterLED ST | 08-2018 | 1.0 | en Determining light output in emergency operation EM converterLED ST 105 200V / EM converterLED ST 105 NiMH 200V LED current at nominal battery voltage and min. battery discharge current LED current at nominal battery voltage and max.
  • Page 31 Product manual EM converterLED ST | 08-2018 | 1.0 | en Determining light output in emergency operation 7.2.1. Example 1: 1 LED module DLE Given: Total forward voltage of all LED modules: 24.2 V (calculated before) Wanted: LED current? Result: Figure: Determining LED current for EM converterLED ST 103 50V The two crossing points are at around 85 mA (minimum value) and 111 mA (maximum value).

  • Page 32: Parameter 3: Light Output In Emergency Operation

    Product manual EM converterLED ST | 08-2018 | 1.0 | en Determining light output in emergency operation 7.3. Parameter 3: Light output in emergency operation The ratio between emergency operation and normal operation is the same for light output and LED current. The values for normal operation can be found in the LED module data sheet, the value for the LED current in emergency operation can be found in the data sheet (see example above).

  • Page 33: Compatibility With Led Module And Led Driver

    Both, the LED module and the LED Driver used in combination with the EM converterLED ST have to be checked for compatibility. 8.1. Compatibility with LED module The total forward voltage of all LED modules (see chapter XX) connected to the EM converterLED ST have to be in its LED module forward voltage range.
  • Page 34 Product manual EM converterLED ST | 08-2018 | 1.0 | en Compatibility with LED module and LED Driver 8.3.3. Conditions When conducting the tests the following conditions must be considered: All tolerances Entire temperature range Different output voltage ranges (incl. no load)

  • Page 35: Installation Notes

    Electronic control gear from Tridonic are protected for a maximum of 48 hour against overvoltage of up to 320 V. Make sure that the control gear is not exposed to overvoltage for long periods! Electronic control gear of the EM converterLED series from Tridonic have type of protection IP 20.

  • Page 36: Routing The Wires

    Product manual EM converterLED ST | 08-2018 | 1.0 | en Installation notes 9.2. Routing the wires 9.2.1. Tests NOTICE The performance of the prescribed tests and compliance with relevant standards are the responsibility of the luminaire manufacturer. The following descriptions merely indicate the most important tests and are no substitute for a full research of the relevant standards.
  • Page 37 Product manual EM converterLED ST | 08-2018 | 1.0 | en Installation notes Wiring the plug-in terminal Use solid wire with the correct cross-section Strip off correct length of insulation; you may need to twist the tool slightly Insert the bare end into the terminal Release of the wiring Press down the “push button”...

  • Page 38: Reference List

    Product manual EM converterLED ST | 08-2018 | 1.0 | en Reference list 10.1. Related documents Data sheet EM converterLED SELFTEST 50V: https://www.tridonic.com/com/en/download/data_sheets/EM_converterLED_SELFTEST_50V_en.pdf Data sheet EM converterLED SELFTEST 90V: https://www.tridonic.com/com/en/download/data_sheets/EM_converterLED_SELFTEST_90V_en.pdf Data sheet EM converterLED SELFTEST 200V: https://www.tridonic.com/com/en/download/data_sheets/EM_converterLED_SELFTEST_200V_en.pdf Data sheet EM converterLED PRO 50V: https://www.tridonic.com/com/en/download/data_sheets/EM_converterLED_PRO_50V_en.pdf...
