Summary of Contents for Wecon LX3V-16EY
- Page 1 Output expansion module user manual Website: http://www.we-con.com.cn/en Technical Support: support@we-con.com.cn Skype: fcwkkj Phone: 86-591-87868869 QQ: 1043098682 Technical forum: http://wecon.freeforums.net/...
- Page 2 Output expansion module General This manual is applied to LX3V-8EY and LX3V-16EY digital output expansion modules. 1. Naming rule Naming rule of LX3V I/O output expansion module: ① WECON PLC; ④ Product type, E means expansion; ② Main module; ⑤ Expansion output(Y);...
- Page 3 Light when photo-coupling is Light when relay is energized energized 2A/ point 0.5A/ point Resistance 8A/ four points 0.8A/ four points 8A/ eight points 1.6A/ eight points Load Inductance 80VA 12W/DC24V Lamp 100W 1.5W/DC24V Leakage current 0.1mA/ DC 30V WECON Technology Co., Ltd.
- Page 4 Output expansion module Minimum load DC 5V 2mA OFF->ON About 10ms Less than 0.2ms ON-> OFF About 10ms Less than 0.2ms Version: V1.0.1 Date: March 2018 WECON Technology Co., Ltd.
