- Page 1 LX3V-8EX/16EX Version 9.1 authored by on 2022/12/15 14:00...
-
Page 2: Table Of Contents
Table of Contents ......................1 Naming rule . -
Page 3: Naming Rule
LX3V-8EX/16EX This manual is applied to LX3V-8EX and LX3V-16EX digital input expansion modules. 1 Naming rule Naming rule of LX3V I/O input expansion module: 1. WECON PLC; 2. Main module; 3. The number of input points 4. Product type: E means expansion; 5. Expansion input(X) 2 Dimensions ... - Page 4 LX3V-8EX/16EX 4 / 8...
- Page 5 LX3V-8EX/16EX 1. Extension cable 2. Input indicator light of each channel 3. LINK: Communication indicator between PLC and expansion module 4. Expansion module name 5. Digital signal output terminal 6. Extension module interface 7. DIN rail mounting slot 8. DIN rail hook 9.
-
Page 6: Crimp Terminals
LX3V-8EX/16EX Software is abnormal or hardware is faulty ✎Note: Except different I/O input points, LX3V-8EX and LX3V-16EX have the same dimensions and the same other functions. Crimp terminals 1. Please use crimp terminals as indicated on the graph. 2. The tightening torque should be applied 5 to 8 Kg.cm. -
Page 7: Instructions
LX3V-8EX/16EX Input signal voltage DC ± 24V ± 10% *1 Input signal current 5mA/ DC 24V Input ON current More than 3.5mA Input OFF current Less than 1.5mA Input response time About 10ms X0 to X7 built-in digital filter, setting time 0 ~ 60ms... - Page 8 LX3V-8EX/16EX As shown in the example above, it is LX3V-3624MT with two LX3V-16EX modules and one LX3V-4DA module. The host has 36 input points X: X0 to X7, X10 to X17, X20 to X27. X30 to X37 and X40 to X43. The input point in the module called by host are X50 to X57 and X60 to X67, and the input points ①...
