KLAY-INSTRUMENTS 2000-SAN Series Instruction Manual

Intelligent pressure- and level transmitters
Hide thumbs Also See for 2000-SAN Series:

Advertisement

PRESSURE- AND LEVEL TRANSMITTERS
Read this manual before working with the product. For personal and system safety and for optimum product
performance, make sure you thoroughly understand the contents before installing, using, or maintaining the
Series 2000, Series 2000-SAN, Series CER-2000 and the Series 2000-Hydrobar.
SERIES 2000
Manufactured by:
www.klay-instruments.com
H/EN/2000-HART/02-2016/23
INSTRUCTION MANUAL ( "HART")
"INTELLIGENT"
SERIES 2000-SAN
SERIES 2000
SERIES CER-2000
SERIES 2000-HYDROBAR
Read the precautions and warnings on page 25.
SERIES 2000-SAN SERIES CER-2000
WARNING
Nijverheidsweg 5
P.O. Box 13
Tel: +31-521-591550
Fax: +31 -521-592046
7991 CZ DWINGELOO
7990 AA DWINGELOO
The Netherlands
E-mail:
info@klay.nl
KLAY INSTRUMENTS B.V.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2000-SAN Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KLAY-INSTRUMENTS 2000-SAN Series

  • Page 1 Series 2000, Series 2000-SAN, Series CER-2000 and the Series 2000-Hydrobar. Read the precautions and warnings on page 25. SERIES 2000 SERIES 2000-SAN SERIES CER-2000 Manufactured by: 7991 CZ DWINGELOO Nijverheidsweg 5 7990 AA DWINGELOO P.O.
  • Page 2: Table Of Contents

    Instruction Manual Series 2000 HART Klay Instruments B.V. CONTENTS SECTION PAGE Introduction Description Series 2000–SAN Description Series 2000 Description Peramic ‘S” (Series CER-2000) Description Series 2000-Hydrobar Barometric reference Dimensional drawings Dimensional drawing 2000-SAN Dimensional drawing 2000 Dimensional drawing CER-2000 Dimensional drawing 2000-Hydrobar Installing transmitter Installing weld-on nipple Installing transmitter Series 2000-SAN...
  • Page 3 Instruction Manual Series 2000 HART Klay Instruments B.V. P110 Simulation of current P111 Linearization 19/20 P112 Specific density P113 Write protection P114 Response time from push buttons P115 Service-menu P116 Service -menu Programming of the series 2000 Programming with the hand held terminal Programming with DTM Programming with PDA Specifications...
  • Page 4: Introduction

    Instruction Manual Series 2000 HART Klay Instruments B.V. INTRODUCTION The SERIES 2000 and SERIES 2000-SAN are solid-state pressure- and level transmitters based upon a bridge resistive silicon sensor, with a very high burst pressure. The sensor element is mounted in a stainless steel foot. A very strong stainless steel "flush" diaphragm protects the sensor from the process medium.
  • Page 5: Dimensional Drawings

    Instruction Manual Series 2000 HART Klay Instruments B.V. DIMENSIONAL DRAWINGS 2.1 DIMENSIONAL DRAWING 2000-SAN PARTS DESCRIPTION MATERIAL Cover SS 304 Pushbutton + Display Cover with venting SS 304 Venting PG9 Cable Gland O-ring (2 pcs) EPDM Electronics housing SS 304 Foot SS 316 Lock ring...
  • Page 6: Dimensional Drawing 2000-Hydrobar

    Instruction Manual Series 2000 HART Klay Instruments B.V. 2.4 DIMENSIONAL PARTS DESCRIPTION MATERIAL DRAWING 2000-HYDROBAR Cover SS 304 Push buttons + Display Cover with venting SS 304 Venting PG9 Cable Gland 2x O-ring EPDM Electronics housing SS 304 2x Connection to cable SS 316 Cable with venting tube PE Foot...
  • Page 7: Installing Transmitter

    Instruction Manual Series 2000 HART Klay Instruments B.V. INSTALLING TRANSMITTER The diaphragm of the transmitter is protected with a special protection cap. Protect the diaphragm until installation takes place. * DO NOT DAMAGE THE DIAPHRAGM. * INSTALLING WELD-ON NIPPLE A certified welder should perform installation of the weld-on nipple. Weld with Argon, MIG or TIG.
  • Page 8: Installing Transmitter Series Cer-2000

    Instruction Manual Series 2000 HART Klay Instruments B.V. INSTALLING TRANSMITTER SERIES CER-2000 The position of the electronic housing is depending on the welding position of the weld-on nipple. Before welding, locate the weld-on nipple so that the cable entry and the venting are in the right direction.
  • Page 9: Remaining

    Instruction Manual Series 2000 HART Klay Instruments B.V. REMAINING DIGITAL LOCAL INDICATOR All transmitters from the Series 2000 are standard equipped with a digital display. In the standard circumstances the covers are "closed". The three push buttons and the display are behind the cover (1).
  • Page 10: Intrinsically Safe / Non Sparking (Ex Version)

    Instruction Manual Series 2000 HART Klay Instruments B.V. INTRINSICALLY SAFE and NON SPARKING (Ex version) The Series 2000, Series 2000-SAN, Series CER-2000 and Series 2000-Hydrobar-cable are also available for intrinsically safe (Zone 0). The Series 2000, Series 2000-SAN, Series 2000- Cable and Series 2000-SAN-Cable are also available for Non-Sparking (Zone 2).
  • Page 11: Functional Safety - Sil

    When ordered as a SIL (Proven in use) transmitter, the safety manual will be supplied. (Option G200). Detailed information can be found in the Safety manual of the instrument. The most recent version of the Safety manual is available on: www.klay-instruments.com under section “Downloads”.
  • Page 12: Traceability Year Of Manufacturing

    Instruction Manual Series 2000 HART Klay Instruments B.V. TRACEBILITY YEAR OF MANUFACTURING The year of manufacturing of the transmitter can be traced as follows: take the first two numbers from the serial number that is engraved in the transmitter and add 1970 to it. For example: if the serial number is 4309036.
  • Page 13: Functions Of Push Buttons

    Instruction Manual Series 2000 HART Klay Instruments B.V. FUNCTIONS OF PUSH BUTTONS The Series 2000 can be programmed easily by use of the 3 front panel pushbuttons (See picture right). The display can show engineering units of: O, inH O, bar and PSI. The functions of the three pushbuttons will be explained below.
  • Page 14: Programming Points (P101-P114)

    Instruction Manual Series 2000 HART Klay Instruments B.V. 6. PROGRAMMING POINTS (P101 – P114) Programming points: P101 Zero adjustment (4 mA) The following points can be adjusted by means of the three push buttons. P102 Span adjustment (20 mA) For an explanation of these points see page P103 Cancel mounting position effect 11 to 18 of this manual.
  • Page 15: Explanation Programming Points P101 To P114

    Instruction Manual Series 2000 HART Klay Instruments B.V. EXPLANATION PROGRAMMING POINTS P101 to P114 P101 ZERO ADJUSTMENT (4 mA) The transmitter as standard is adjusted to 4.00 mA at atmospheric pressure. It is also possible to adjust a zero-suppression or elevation. For example: zero elevation of 1 mWK.
  • Page 16: P103 Cancel Mounting Position Effect

    Instruction Manual Series 2000 HART Klay Instruments B.V. P103 CANCEL MOUNTING POSITION EFFECT All transmitters are calibrated vertically. When a transmitter of the Series 2000 or 2000-SAN is installed horizontally, there will be a small "mounting effect" on the zero (4 mA).
  • Page 17: P104 Adjustment Pressure Unit On Display

    Instruction Manual Series 2000 HART Klay Instruments B.V. P104 ADJUSTMENT PRESSURE UNIT ON DISPLAY (See Conversion table) Several engineering units can be shown on the display by using a conversion factor. (See conversion table below). As standard the pressure unit of the transmitter is set to bar.
  • Page 18: P105 Reverse Output (20-4 Ma)

    Instruction Manual Series 2000 HART Klay Instruments B.V. P105 REVERSE OUTPUT (20 - 4 mA) The transmitter as standard is adjusted to 4-20 mA. Push on [PROG] and go to P105. Push once at [] to change the output to 20-4 mA (Reverse output). Push at [PROG] to confirm this.
  • Page 19: H/En/2000-Hart/08

    Instruction Manual Series 2000 HART Klay Instruments B.V. P110 SIMULATION OF CURRENT (4-20 mA) The transmitter can be used as a simulator of a current between 4 - 20 mA. This can be done in P110 with the push buttons [] and []. The user can perform a current simulation (Curr) or a pressure simulation (Unit).
  • Page 20 Instruction Manual Series 2000 HART Klay Instruments B.V. As standard the transmitter is delivered without Linearization (= 0). However, for a horizontal tank or a tank with a bottom cone, a Linearization can be applied to achieve the current signal (mA) is equal to the level in the tank. All values must be programmed in meters.
  • Page 21 Instruction Manual Series 2000 HART Klay Instruments B.V. Linearization vertical tank with cone Push [PROG] till "100" appears on the display. Push 11 times at [] till "111" appears. (Confirm with [PROG]) Push twice at []. (Confirm with [PROG]) Enter height (H1) of the tank (= actual level).(Confirm with [PROG]).
  • Page 22: P112 Specific Density

    Instruction Manual Series 2000 HART Klay Instruments B.V. 6. SET MAX appears on the display, and the maximum value can be set, by using the arrow [] buttons. Confirm with [PROG]. 7. To display this configuration on the display navigate to P109. Choose FREE and confirm with [PROG].
  • Page 23: Programming With The Hand Held Terminal

    HART transmitters easy. This DTM can be used with almost every FDT-container. The most recent version of the DTM file (zip file) is available on: www.klay-instruments.com under section “Downloads”. Unzip DTM Klay Series 2000 HART V1-2-0-1.zip and run DTM Klay Series 2000 HART V1-2-0-1.exe.
  • Page 24: Specifications

    Instruction Manual Series 2000 HART Klay Instruments B.V. SPECIFICATIONS Manufacturer Klay Instruments B.V. Instrument Series 2000, Series 2000-SAN, Series CER-2000 and 2000-Hydrobar Output 4-20 mA ® Optional: HART Protocol 12 – 36 Vdc Power Supply Standard : 12 – 26,5 Vdc Ex : ®...
  • Page 25: Precautions And Warnings

    (technical field) and therefore does not warrant the suitability of its product for the application selected by the customer. Manufactured by: Nijverheidsweg 5 P.O. Box 13 7991 CZ DWINGELOO Tel: +31-521-591550 7990 AA DWINGELOO www.klay-instruments.coml Fax: +31 -521-592046 The Netherlands E-mail: info@klay.nl H/EN/2000-HART/08-2016/24 Page 25...
  • Page 26 EU-DECLARATION OF CONFORMITY Klay Instruments B.V. Nijverheidsweg 5, 7991 CZ Dwingeloo, The Netherlands Certify that the equipment intended for use in potentially explosive atmospheres, only new products, indicated here after: Electronic Pressure / Level Transmitter Series 2000, Series 2000-SAN, Series 2000-Cable, Series 2000-SAN-Cable, Series CER-2000 and Series 2000-Hydrobar-Cable, Series 2000-Hydrobar-EXTD, Temperature Transmitter Type TT-2000 and Pressure / Level Transmitter Hydrobar-I-Cable.
