KLAY-INSTRUMENTS 2000-SAN Series Instruction Manual

Pressure- and level transmitters
Hide thumbs Also See for 2000-SAN Series:
Table of Contents

Advertisement

Quick Links

Download this manual
PRESSURE- AND LEVEL TRANSMITTERS
Read this manual before working with the product. For personal and system safety and for optimum product
performance, make sure you thoroughly understand the contents before installing, using, or maintaining the
Series 2000-SAN. Read the precautions and warnings on the last page.
Manufactured by:
www.klay-instruments.com
H/EN/2000-SAN-3A/01-2021/24
INSTRUCTION MANUAL
Series 2000-SAN
According to 3A requirements (option G153)
WARNING
Nijverheidsweg 5
P.O. Box 13
Tel: +31 521-591550
Fax: +31 521-592046
7991 CZ DWINGELOO
7990 AA DWINGELOO
The Netherlands
E-Mail:
info@klay.nl
KLAY INSTRUMENTS B.V.

Advertisement

Table of Contents
loading

Related Manuals for KLAY-INSTRUMENTS 2000-SAN Series

Summary of Contents for KLAY-INSTRUMENTS 2000-SAN Series

  • Page 1 Series 2000-SAN. Read the precautions and warnings on the last page. Manufactured by: Nijverheidsweg 5 7991 CZ DWINGELOO P.O. Box 13 7990 AA DWINGELOO Tel: +31 521-591550 The Netherlands www.klay-instruments.com Fax: +31 521-592046 E-Mail: info@klay.nl H/EN/2000-SAN-3A/01-2021/24 KLAY INSTRUMENTS B.V.
  • Page 2 CONTENTS SECTION PAGE Introduction Description Series 2000–SAN Barometric reference Dimensional drawings Dimensional drawing 2000-SAN 3A-W-Weld-on Dimensional drawing 2000-SAN 3A-X7-DRD-FLANGE Dimensional drawing 2000-SAN 3A-X4-VARIVENT Dimensional drawing 2000-SAN 3A-TRI-CLAMP Installing transmitter Installing weld-on nipple Installing transmitter Series 2000-SAN Mounting position Mounting position effect Calibration Wiring Remaining...

  • Page 3: Table Of Contents

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. Explanation programming points P101 to P114 P101 Zero adjustment (4 mA) P102 Span adjustment (20 mA) without test pressure P103 Cancel mounting position effect P104 Adjustment pressure unit on display P105 Reverse output (20-4 mA) P106 Adjustment damping (0 till 25 sec) P107 Indication of process temperature P108 Temperature in °C of °F...
  • Page 4 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. INTRODUCTION The SERIES 2000-SAN are solid-state pressure- and level transmitters based upon a bridge resistive silicon sensor, with a very high burst pressure. The sensor element is mounted in a stainless steel foot. A very strong stainless steel "flush" diaphragm protects the sensor from the process medium.
  • Page 5 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. DIMENSIONAL DRAWINGS 2.1 DIMENSIONAL DRAWING 2000-SAN PARTS DESCRIPTION MATERIAL 1. Cover AISI 304 2. Pushbutton + Display(behind cover) 3. Cover with venting AISI 304 4. Venting 5. PG9 Cable Gland 6. 2xO-ring (55,25 x 2,62) EPDM 7.
  • Page 6 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. 2.2 DIMENSIONAL DRAWING 2000-SAN PARTS DESCRIPTION MATERIAL Cover AISI 304 Pushbutton + Display (behind cover) Cover with venting AISI 304 Venting PG9 Cable Gland O-Ring (2x) EPDM Electronics housing AISI 304 Flange AISI 304 Foot with sensor AISI 316L Diaphragm...
  • Page 7 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. 2.3 DIMENSIONAL DRAWING 2000-SAN PARTS DESCRIPTION MATERIAL Cover AISI 304 Pushbuttons + Display (behind cover) Cover with venting AISI 304 Venting PG9 Cable Gland O-Ring (2x) EPDM Electronics housing AISI 304 ‘Varivent’ Baseplate AISI 316 Diaphragm AISI 316L...
  • Page 8 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. INSTALLING TRANSMITTER The diaphragm of the transmitter is protected with a special protection cap. Protect the diaphragm until installation takes place. * DO NOT DAMAGE THE DIAPHRAGM. *. INSTALLING WELD-ON NIPPLE A skilled machinist or welder should perform installation of the weld-on nipple. Weld Argon, MIG or TIG with the smallest welding pin.
  • Page 9 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. MOUNTING POSITION When the transmitter is mounted horizontally, the cable gland MUST be pointed downwards. MOUNTING POSITION EFFECT All transmitters are calibrated in vertical position. If the transmitter is mounted in a different position, there will be a little zero shift. If the transmitter is mounted up, there is a zero shift (e.g.
  • Page 10 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. REMAINING DIGITAL LOCAL INDICATOR All transmitters from the Series 2000 are standard equipped with a digital display. In the standard execution the covers are "closed". The three push buttons and the display are behind the cover (3).
  • Page 11 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. INTRINSICALLY SAFE and NON SPARKING (Ex version) The Series 2000, Series 2000-SAN, Series CER-2000 and Series 2000-Hydrobar-cable are also available for intrinsically safe (Zone 0). The Series 2000, Series 2000-SAN, Series 2000- Cable and Series 2000-SAN-Cable are also available for Non-Sparking (Zone 2). ATEX –...
  • Page 12 When ordered as a SIL (Proven in use) transmitter, the safety manual will be supplied. (Option G200). Detailed information can be found in the Safety manual of the instrument. The most recent version of the Safety manual is available on: http://www.klay-instruments.com under section “Downloads”.
  • Page 13 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. TRACEABILITY YEAR OF MANUFACTURING The year of manufacturing of the transmitter can be traced as follows: take the first two numbers from the serial number that is engraved in the transmitter and add 1970 to it. For example: if the serial number is 4309036.
  • Page 14 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. 6. PROGRAMMING POINTS (P101 – P114) Programming points: P101 Zero adjustment (4 mA) The following points can be adjusted by means of the three push buttons. P102 Span adjustment (20 mA) For an explanation of these points see page P103 Cancel mounting position effect 11 to 18 of this manual.

  • Page 15: Explanation Programming Points P101 To P114

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. EXPLANATION PROGRAMMING POINTS P101 to P114 ZERO ADJUSTMENT (4 mA) P101 The transmitter as standard is adjusted to 4.00 mA at atmospheric pressure. It is also possible to adjust a zero-suppression or elevation. For example: zero elevation of 1 mWK.

  • Page 16: P103 Cancel Mounting Position Effect

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. CANCEL MOUNTING POSITION EFFECT P103 All transmitters are calibrated vertically. When a transmitter of the Series 2000-SAN is installed horizontally, there will be a small "mounting effect" on the zero (4 mA). For example, the transmitter shows 4.03 mA instead of 4.00 mA. This can be easily canceled with P103.

  • Page 17: P104 Adjustment Pressure Unit On Display

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. P104 ADJUSTMENT PRESSURE UNIT ON DISPLAY (See Conversion table) Several engineering units can be shown on the display by using a conversion factor. (See conversion table below). Four engineering units will light up on the display O, inH O, bar and PSI).

  • Page 18: P105 Reverse Output (20-4 Ma)

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. P105 REVERSE OUTPUT (20 - 4 mA) The transmitter as standard is adjusted to 4-20 mA. Push on [PROG] and go to P105. Push once at [] to change the output to 20-4 mA (Reverse output). Push at [PROG] to confirm this.

  • Page 19: P110 Simulation Of Current

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. SIMULATION OF CURRENT (4-20 mA) P110 The transmitter can be used as a simulator of a current between 4 - 20 mA. This can be done in P110 with the push buttons [] and []. The user can perform a current simulation (Curr) or a pressure simulation (Unit).
  • Page 20 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. Linearization horizontal tank (Cylindrical) Cylindrical horizontal tank Cylindrical tank with cone-shaped ends Push [PROG] until "100" is shown on the display. Push 11 x at [] / SPAN till "111" appears. (Confirm with [PROG]) Push [] once.

  • Page 21: P112 Density

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. Linearization vertical tank with cone Push [PROG] till "100" appears on the display.  Push 11 times at [ ] till "111" appears. (Confirm with [PROG])  Push twice at [ ]. (Confirm with [PROG]) Enter height (H1) of the tank (= actual level).

  • Page 22: P113 Write Protection

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. Changes via external HART configuration software by the Hand-held terminal or the P.C. ("C.Pro."= Communication Protection). Standard, the transmitter is set to no-write protection. Adjustment Local Protection Push [PROG] till "100" appears on the display. Push [] / SPAN 13 times till "113"...

  • Page 23: Programming Of The Series 2000

    HART transmitters easy. This DTM can be used with almost every FDT-container. The most recent version of the DTM file (zip file) is available on: www.klay-instruments.com under section “Downloads”. Unzip DTM Klay Series 2000 HART V1-2-0-1.zip and run DTM Klay Series 2000 HART V1-2-0-1.exe.

  • Page 24: Specifications

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. SPECIFICATIONS Manufacturer Klay Instruments B.V. Instrument Series 2000-SAN, Output 4-20 mA Optional: HART Protocol Power Supply 12 - 36 Vdc Ex-version: 12 - 26,5 Vdc Accuracy 0,1% of adjusted span Ranges Max. Adjustable span ranges Code overpressure.

  • Page 25: Precautions And Warnings

    (technical field) and therefore does not warrant the suitability of its product for the application selected by the customer. Manufactured by: 7991 CZ DWINGELOO Nijverheidsweg 5 7990 AA DWINGELOO P.O. Box 13 The Netherlands Tel: +31-521-591550 E-mail: info@klay.nl Fax: +31 -521-592046 www.klay-instruments.com H/EN/2000-SAN-3A/05-2021/25 Page 25...

  • Page 26: Attachment: Ec-Declaration Of Conformity

    Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. Attachment: EC-Declaration of conformity EU-DECLARATION OF CONFORMITY Klay Instruments B.V. Nijverheidsweg 5, 7991 CZ Dwingeloo, The Netherlands Certify that the equipment intended for use in potentially explosive atmospheres, only new products, indicated here after: Electronic Pressure / Level Transmitter Series 2000, Series 2000-SAN, Series 2000-Cable, Series 2000-SAN-Cable, Series CER-2000 and Series 2000-Hydrobar-Cable, Series 2000-Hydrobar-EXTD, Hydrobar-I-Cable and Temperature Transmitter Series TT-2000.
  • Page 27 Instruction Manual Series 2000-SAN-3A Klay Instruments B.V. equipment for use with dust equipment in compliance with European standards for explosive atmospheres equipment in compliance with specific building rules for intrinsically save equipment equipment in compliance with specific building rules for intrinsically save equipment equipment in compliance with specific building rules for non-sparking save equipment equipment for use with gas of subdivision C...
