KLAY-INSTRUMENTS 8000-SAN Series Quick Start Manual

Pressure and level transmitters

Advertisement

Quick Links

PRESSURE AND LEVEL TRANSMITTERS
Read this manual before working with the product. For personal and system safety, and for optimum
product performance, make sure you thoroughly understand the contents before installing, using, or
SERIES 8000-SAN
Manufactured by :
www.klay-instruments.com
H/US/8000/03-2018/00
WARNING
maintaining the Series 8000 or Series 8000-SAN.
Nijverheidsweg 5
P.O. Box 13
Tel: +31-521-591550
Fax: +31 -521-592046
Klay Instruments
SERIES 8000
7991 CZ DWINGELOO
7990 AA DWINGELOO
The Netherlands
E-mail:
info@klay.nl
Page 1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8000-SAN Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for KLAY-INSTRUMENTS 8000-SAN Series

  • Page 1 Series 8000 or Series 8000-SAN. SERIES 8000-SAN SERIES 8000 Manufactured by : Nijverheidsweg 5 7991 CZ DWINGELOO P.O. Box 13 7990 AA DWINGELOO Tel: +31-521-591550 The Netherlands www.klay-instruments.com Fax: +31 -521-592046 E-mail: info@klay.nl H/US/8000/03-2018/00 Klay Instruments Page 1/8...
  • Page 2: Table Of Contents

    CONTENTS SECTION PAGE SECTION PAGE Introduction Wiring Description Series 8000-SAN Digital Local Indicator Description Series 8000 Hazardous area (Ex) Functional Safety – SIL Barometric reference Traceability year of manufacturing Dimensional Drawing CE / EMC-rules Dimensional Drawing 8000-SAN External Load Dimensional Drawing 8000 Installing Weld-on nipple Specifications Installing Transmitter...
  • Page 3: Dimensional Drawing 8000

    DIMENSIONAL DRAWING 8000-SAN: PARTS DESCRIPTION: MATERIAL: 1. Cover AISI 304 2. O-Ring EPDM 3. Venting 4. PG9 Cable Gland 5. Electronic Housing AISI 304 6. Foot AISI 304 7. Diaphragm and ring AISI 316 8. Lock ring AISI 304 9. Weld-on nipple AISI 316 L 10.
  • Page 4: Installing Transmitter 8000

    Position the weld-on nipple in the vessel hole and tack six places. The weld sequence is shown in the figure above. Weld the weld-on nipple in place using 0.03 to 0.045 inch. (0.762 to 1.143 mm) stainless rod as filler material in the bevelled area.
  • Page 5: Wiring

    WIRING: The connector, and zero/span potentiometers are under the cover. Test nipples for calibration of the Series 8000 and Series 8000-SAN are available on request. External loads must be placed in the negative side of the 2-wire loop. The figure left shows the wiring connection of the transmitter. The 2- wires must be connected to connectors 3 (-) and 4 (+) of the terminal board.
  • Page 6: Functional Safety - Sil

    When ordered as a SIL (Proven in use) transmitter, the safety manual will be supplied. (Option G200) Detailed information can be found in the Safety manual of the instrument. The most recent version of the Safety manual is available on: www.klay-instruments.com under section downloads. TRACEABILITY YEAR OF MANUFACTURING: The year of manufacturing of the transmitter can be traced as follows: take the first two numbers from the serial number that is engraved in the transmitter and add 1908.
  • Page 7: Specifications

    SPECIFICATIONS Manufacturer Klay Instruments Series 8000 Instrument Series 8000-SAN Output 4-20 mA 12 - 36 Vdc Power Supply Ex-version: 13 - 26.5 Vdc Accuracy 0.2 % of adjusted span Process Temperature -4 °F to 176 °F Series 8000 -4 °F to 212 °F Series 8000-SAN -4 °F to 176 °F Series 8000-Cable...
  • Page 8: Precautions And Warnings

    Instruments is not an expert in the customer’s process (technical field) and therefore does not warrant the suitability of its product for the application selected by the customer. Manufactured by: Nijverheidsweg 5 7991 CZ DWINGELOO P.O. Box 13 7990 AA DWINGELOO Tel: +31-521-591550 The Netherlands www.klay-instruments.com Fax: +31-521-592046 E-mail: info@klay.nl Page 8/8 H/US/8000/03-2018/00 Klay Instruments...
  • Page 9 EU-DECLARATION OF CONFORMITY Klay Instruments B.V. Nijverheidsweg 5, 7991 CZ Dwingeloo, The Netherlands Certify that the equipment for use in potentially explosive atmospheres, only new products, indicated here after: Electronic Pressure- and Level Transmitters Series 8000-SAN, Series 8000, Series CER-8000 Hydrobar-Cable, Hydrobar-EXTD, Hydrobar-FR Are in accordance with: - Directive 2014/34/EU (Equipment and protective systems for use in potentially explosive atmospheres)

This manual is also suitable for:

8000 series
