4. TECHNICAL SPECIFICATIONS
VERSION
PUMP VERSION
Paint Passages
Air Working Pressure range
Max. Fluid Working Pressure
Air Inlet
Fluid Outlet
Fluid Inlet
Paint Delivery at 30 cyc/min
Paint Delivery at 200 cyc/min
Paint Viscosity
Working Temperature
Compressor (required power)
Noise Level
Performance Curve
DPS-70 C.TE
DDP-70B
Aluminium
1.5~7 bar (22~100 psi)
7 bar (100 psi)
0.6 lt./min
6 lt./min
60sec/Ford#4
5~40°C
0.4~0.75 kW
66 dB(A)
* 0.3/0.5/0.7 MPa in graph shows air pressure
* Test by turpentine
DPS-70 CN.TE
DDP-70 BN
Stainless Steel
G 1/4"
G 3/8"
G 1/4"
