COMPONENTS DESCRIPTION
CONTROL PANEL
Start-up
On start-up, all LEDs light up for 3 seconds after displaying the software version and build.
Functions
+
+
Pg. 13
treesse
Filling
The fill mechanism is triggered by pressing SPA and scroll DOWN
together.
The function is confirmed when the FILLING LED is on.
When filling is complete and all necessary conditions for the product
to function are satisfied, the system stops automatically and makes
the
SPA, RECIRCULATE, OZONE and HEATER functions
available.
During filling, if the time to reach minimum level (90 mins) and
maximum level (15 mins) of water in the tub's expansion tank is not
satisfied, the system will display a warning message
(minimum level) or "AL2" (maximum level), blocking all functions as a
result.
In this case the tub will have to be shut down, then started up again
after waiting 30 seconds, using the product's main switch.
While the spa is in use, the system automatically keeps the water level
at the edge of the tub.
Draining
T h e d r a i n i n g m e c h a n i s m i s t r i g g e r e d b y p r e s s i n g
CHROMOTHERAPY and scroll DOWN together.
The function is confirmed when the DRAINING LED is on.
This function can be activated at any time.
When DRAINING is on, all other functions are disabled.
During draining, if the time to reach minimum level (60 mins) of water
in the tub's expansion tank is not satisfied, the system will display a
warning message "AL3", blocking all functions as a result.
In this case the tub will have to be shut down, then started up again
after waiting 30 seconds, using the product's main switch.
"AL1"
treesse
