Summary of Contents for treesse Fusion SKI
- Page 1 Fusion SKI Pre-installation manual...
- Page 2 For this reason we advise you to read this manual carefully and to carefully follow all the information contained herein. The Treesse team is always available for any information or request for assistance that may be required during preparation.
-
Page 3: Table Of Contents
Contents FUSION SKI - MEASUREMENTS AND TECHNICAL SPECIFICATIONS __________ 4 FUSION SKI - MEASUREMENTS AND TECHNICAL SPECIFICATIONS __________ 6 FUSION SKI - MEASUREMENTS AND TECHNICAL SPECIFICATIONS ___________ 8 FUSION SKI - MEASUREMENTS AND TECHNICAL SPECIFICATIONS ___________ 10 WHAT PREPARATIONS ARE REQUIRED? _______________________ 13... -
Page 4: Fusion Ski
Pre-Installation Fusion SKI bathtub FUSION SKI - MEASUREMENTS AND TECHNICAL SPECIFICATIONS 200 x 200 x 66 cm (78.7 x 78.7 x 26 inches) 660 litres maximum water (173 gal) content Packaging Freestanding Recessed Drain 845 kg The manufacturer suggests a... - Page 5 Pre-Installation Fusion SKI bathtub A Cold + hot water connection, 1/2" male AF: cold water AC: hot water B Floor drain ø40 C Electrical connection (power cord type H05 with three wires (single-phase 230V)
- Page 6 Pre-Installation Fusion SKI bathtub FUSION SKI - MEASUREMENTS AND TECHNICAL SPECIFICATIONS 230 x 150 x 66 cm (90.5 x 59 x 26 inches) 620 litres maximum water (164 gal) content Packaging Freestanding Recessed Drain 765 kg The manufacturer suggests a...
- Page 7 Pre-Installation Fusion SKI bathtub A Cold + hot water connection, 1/2" male AF: cold water AC: hot water B Floor drain ø40 C Electrical connection (power cord type H05 with three wires (single-phase 230V)
-
Page 8: Fusion Ski - Measurements And Technical Specifications
Pre-Installation Fusion SKI bathtub FUSION SKI - MEASUREMENTS AND TECHNICAL SPECIFICATIONS 220 x 120 x 66.5 cm (86.6 x 47.2 x 26.2 inch) 520 litres maximum water (137gal) content Packaging Freestanding Recessed Drain The manufacturer suggests a 670 kg weight... - Page 9 Pre-Installation Fusion SKI bathtub A Cold + hot water connection, 1/2" male AF: cold water AC: hot water B Floor drain ø40 C Electrical connection (power cord type H05 with three wires (single-phase 230V) Standard left Right version on version...
- Page 10 Pre-Installation Fusion SKI bathtub FUSION SKI - MEASUREMENTS AND TECHNICAL SPECIFICATIONS 180 x 230 x 66.5 cm (70.8 x 90.5 x 26.2 inches) 1000 litres maximum water (265 gal) content Packaging Freestanding Recessed Drain 1210 kg The manufacturer suggests a...
- Page 11 Pre-Installation Fusion SKI bathtub A Cold + hot water connection, 1/2" male AF: cold water AC: hot water B Floor drain ø40 C Electrical connection (power cord type H05 with three wires (single-phase 230V) Standard left Right version on version...
- Page 12 Pre-Installation Fusion SKI bathtub The bathtub works efficiently and safely if it is installed correctly and in compliance with the regulations in force in the country of use. This pre-installation guide provides information for a proper preparation of the environments and the plumbing and electrical connections.
-
Page 13: What Preparations Are Required
Pre-Installation Fusion SKI bathtub WHAT PREPARATIONS ARE REQUIRED? To be installed, the bathtub requires: Identification of the installation site. Room for the electrical Preparation of the installation site. connections Preparation of the plumbing. Preparation of the electrical system. The following pages will provide detailed explanations of how to perform these preparations. -
Page 14: Identification Of The Installation Site
Pre-Installation Fusion SKI bathtub IDENTIFICATION OF THE INSTALLATION SITE When choosing the position, take into account the local regulations that prohibit any electrical installation (plug sockets, switches, lamps, etc.) in the area surrounding the bathtub for a distance of at least 60 cm and a height of 230 cm. -
Page 15: Preparation Of The Installation Site
Pre-Installation Fusion SKI bathtub PREPARATION OF THE INSTALLATION SITE FREESTANDING INSTALLATIONS As a base, create a platform or flooring in reinforced concrete, able to support the weight of the bathtub and the people using it. The manufacturer suggests a minimum load of 350 kg/m In any case contact a qualified construction engineer to calculate the appropriate load for the installation site. -
Page 16: Recessed Installations
Pre-Installation Pre-Installation Fusion SKI bathtub "A" positioned on the side where the bathtub components RECESSED INSTALLATIONS are situated. Prepare: As a base, create a reinforced concrete recess having a thickness that is able to support the weight of the bathtub A A technical inspection port at least 50 cm wide on all and the people using it. - Page 17 Pre-Installation Fusion SKI bathtub Flooring (it is recommended to choose a flooring 2 Ø15 cm vents to ensure that minimises the possibility of slipping when proper ventilation of the getting in and out of the bathtub) technical compartment Insulation See the plumbing...
-
Page 18: Plumbing Preparations
Pre-Installation Fusion SKI bathtub PLUMBING PREPARATIONS The water connection must be dedicated exclusively to the bathtub (it is not possible to connect other equipment to the same connection) and carried out with new and never used hoses and couplings. It is recommended to use ONLY tap water as it guarantees microbiological purity and absence of metallic particles or organic substances. - Page 19 Pre-Installation Fusion SKI bathtub EXAMPLE OF PRE-INSTALLATION PLUMBING FOR A BATHTUB Connect the drain of the floor Connection to the bathtub using the 1/2 bathtub. The plumber is responsible inch female hoses provided. for the choice and type of materials...
-
Page 20: Electrical Preparations
ELECTRICAL PREPARATIONS • Controlled by a multi-pole switch with a contact gap of The Treesse minipools are built in compliance with European laws (EN 60 335-2-60) and are tested during at least 3 mm and a breaking capacity equal to 60A (or production to ensure the safety of the installer and user. - Page 21 Pre-Installation Fusion SKI bathtub 220V~ ELECTRICAL DIAGRAM CN19 CAVO ALIM. RUBINETTO ELETTRONICO *CN1: CN19 ELECTRONIC TAP CABLE 1- ROSSO-BLU RED-BLUE CN19 2- / SPOT *CN1-**CN3-***CN4 CAVO DISPLAY+SERIALE RICEV. 3- GRIGIO-ROSA GREY-PINK TRASF. 4- / *CN1-**CN3-***CN4 DISPLAY+SERIAL RECEIV. CABLE 40VA **CN3:...
- Page 22 Notes Notes...
- Page 23 Maximum care has been paid to guarantee the accuracy of this manual. The Manufacturer reserves the right to modify the equipment or the documentation at any time, without notice. Therefore there might be small differences between this manual and the product you have received: we apologise in advance for any inconvenience. The total or partial reproduction of this manual without the Manufacturer's consent is prohibited.
- Page 24 www.gruppotreesse.it GRUPPO TRE S s.p.a. 01036 Nepi (VT) - Italy S.S. Cassia km. 36.400 Settevene industrial area tel. (+39) 0761 527242 fax (+39) 0761 527223 info@gruppotres.it...
