Basic Functions: V-Wing™ And Revolution™ Plows - Sno-Way PROCONTROL II Installation & Owner's Manual

4. The button just below the joystick (Figure 1-13, C) is
the "Down Pressure" button. Pressing the button will turn
on the down pressure and an orange indicator light on
the button will glow (DP light). Pressing the button again
will turn the down pressure off.
C
Figure 1-13
The down pressure button is also used to reverse the
raise and lower functions. To reverse the up / down
function hold the Down Pressure button for 10 seconds.
The backlights will flash twice to indicate the change has
taken place. To return to the default setting simply press
and hold the button for 10 seconds.
Basic Functions:
V-Wing™ and Revolution™ Plows
1. The button on the upper left side of the joystick
(Figure 1-14, D) is the Driver's Side Wing button. Push
the top button to perform a driver's side wing extend
function. Push the bottom button to perform a driver's
side wing retract function.
D
Figure 1-14
2. The button to the upper right side of the joystick
(Figure 1-14, E) is the Passenger's Side Wing button.
Push the top button to perform a passenger side wing
extend function. Push the bottom button to perform a
passenger side wing retract function.
E
11
