DEMO MANUAL DC1738A
parts List
ITEM
QTY
REFERENCE
Required Circuit Components
1
1
C1
2
1
C2
3
1
C4
4
1
C8
5
1
C9
6
1
C10
7
1
C12
8
1
R1
9
1
R3
10
2
R4, R7
11
1
R6
12
1
R9
13
1
U1
Additional Demo Board Circuit Components
1
0
C3, C6 (OPT)
2
0
C5 (OPT)
3
0
C7 (OPT)
4
1
C11
5
0
R2, R5, R8 (OPT)
6
0
FB1 (OPT)
7
0
L1 (OPT)
Hardware: For Demo Board Only
1
8
E1-E8
2
3
JP1-JP3
3
1
JP4
4
4
J1-J4
5
1
J5
6
4
XJP1-XJP4
7
4
MTGS AT 4 CORNERS STAND-OFF, SNAP-ON, NYLON, 0.50" TALL
4
PART DESCRIPTION
CAP., X7R, 10µF, 50V, 10%, 1210
CAP., X7R, 0.01µF, 16V, 5%, 0603
CAP., X5R, 100µF, 6.3V, 20%, 1210
CAP., POSCAP, 470µF, 4V, D3L
CAP., X5R, 10µF, 10V, 20%, 0805
CAP., X5R, 4.7µF, 4V, 20%, 0603
CAP., X5R, 22µF, 10V, 20%, 0805
RES., CHIP, 402kΩ, 1/10W, 1%, 0603
RES., CHIP, 165kΩ, 1/16W, 1%, 0603
RES., CHIP, 100kΩ, 1/16W, 1%, 0603
RES., CHIP, 0Ω, 1/4W, 1%, 1206
RES., CHIP, 49.9Ω, 1/16W, 1%, 0603
IC., MODULE REGULATOR, LTM8028EY, BGA-114 LEAD
CAP., 1210
CAP., 0603
CAP., ALUM
CAP., ALUM, 22µF, 50V
RES., CHIP, 0603
FERRITE BEAD, M TYPE
IND., 10µH
TESTPOINT, TURRET, 0.094"
JMP, 0.079", SINGLE ROW HEADER, 4 PIN
JMP, 0.079", SINGLE ROW HEADER, 3 PIN
CONN, BANANA JACK, KEYSTONE-575-4
CONN, BNC
SHUNT, 0.079" CENTER
MANUFACTURER/PART NUMBER
MURATA, GRM32ER71H106K
AVX, 0603YC103JAT2A
AVX, 12106D107MAT2A
SANYO, 4TPF470ML
TAIYO YUDEN, LMK212ABJ106MG-T
AVX, 06034D475MAT2A
TAIYO YUDEN, LMK212BBJ226MG-T
VISHAY, CRCW0603402KFKEA
VISHAY, CRCW0603165KFKEA
VISHAY, CRCW0603100KFKEA
NIC, NRC12ZOTRF
VISHAY, CRCW060349R9FKEA
LINEAR TECHNOLOGY CORPORATION, LTM8028EY
SUN ELECT., 50CE22BS
TAIYO YUDEN, FBMJ3216HS800T
VISHAY, IHLP-2525CZ-01
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM-104-02-L-S
SAMTEC, TMM-103-02-L-S
KEYSTONE, 575-4
CONNEX, 112404
SAMTEC, 2SN-BK-G
dc1738af
