P20-195 Rev. D; ECN 17-15-004
Form No. 034016 • 5/12
Page 1 of 6
2/23/2017
Installation
Model 35370
Kimberly-Clark Corp.
SS Recessed Wall Unit With Waste Receptacle
Coordinate installation with architect and contractor to avoid
protrusion from opposite wall, pipes vent, conduits, electrical
wiring etc. in wall. Follow all applicable local building codes. If
installing where unit projects above top of wainscot, provide
aluminum channel or other filler to prevent gap from finished
wall and flange of unit. For block walls, use metal expansion
shields (not included).
Advertisement
Related Manuals for Kimberly-Clark 35370
Summary of Contents for Kimberly-Clark 35370
- Page 1 Installation Model 35370 Kimberly-Clark Corp. SS Recessed Wall Unit With Waste Receptacle Coordinate installation with architect and contractor to avoid protrusion from opposite wall, pipes vent, conduits, electrical wiring etc. in wall. Follow all applicable local building codes. If installing where unit projects above top of wainscot, provide aluminum channel or other filler to prevent gap from finished wall and flange of unit.
- Page 2 35370 Installation The dispenser housing is sold separately and is not included Installation with this stainless steel wall unit. However, the dispenser housing is required to complete the installation of the wall unit. Dispenser Housing 31501 = 11½" (292) Dispenser Housing 31498 = 11" (279)* 4"...
-
Page 3: Installation
Installation Modèle 35370 Kimberly-Clark Corp. Appareil mural encastré inox à poubelle Coordonner la pose avec l’architecte et l’entrepreneur afin d’éviter une saillie du mur opposé et les tuyaux, bouches d’aération, gaines, câblages électriques, etc. dans le mur. Respecter le code du bâtiment en vigueur. Si l’appareil doit être posé... - Page 4 35370 Installation Le logement de distributeur est vendu séparément et ne sont Installation pas fournis avec cet appareil mural en acier inoxydable. Toutefois, le logement de distributeur est nécessaire pour compléter la pose de l’appareil mural. Logement de distributeur 31501 = 11½"...
-
Page 5: Instalación
Instalación Modelo 35370 Kimberly-Clark Corp. Unidad inox de pared empotrada con recipiente para desechos Coordine la instalación en la pared con un arquitecto y un contratista para evitar que sobresalga de la pared opuesta, de la ventilación de las tuberías, conductos, cableado eléctrico, etc. - Page 6 35370 Instalación La carcasa del dispensador se vende por separado y no viene Instalación con esta unidad de pared de acero inoxidable. Sin embargo, se requiere la carcasa del dispensador para completar la instalación de la unidad de pared. Carcasa del dispensador 31501 = 11½"...
