Kimberly-Clark SCOTT 09505 Manual

Product Codes 09505 White, 09506 Black
Install Dispenser Bracket Installation
Enclosed
(x4)
IMPORTANT! For secure mounting, follow these
instructions thoroughly. Ensure that the proper
mounting hardware is used for the appropriate wall
type.
1. Open dispenser. Keys and screws are
included with each dispenser (Figure 1).
2. Mark wall such that lever is 48" from the
floor so dispenser can be mounted directly
above the toilet bowl.
3. With lever at proper level, place open
dispenser back against wall and attach
(Figure 2). Note: use four screws to keep
dispenser secure.
OPTIONAL PUSH BUTTON LOCK FEATURE
Dispenser comes with plug in place. To convert to
pushbutton operation:
SCOTT® PERSONAL SEAT COVER DISPENSER
DISTRIBUTRICE DE COUVRE-SIÈGES INDIVIDUELS SCOTT®
Tools Required:
(x4) (x1)
48" from
floor
*Check for ADA
regional & local
installing/mounting
requirements.
1.
Use correct
drill bit for
anchor size
Form 034172
