Installation instructions for the KIMBERLY-CLARK PROFESSIONAL
STAINLESS STEEL RECESSED DISPENSING SYSTEMS Code: 31501
IMPORTANT! For secure mounting, follow instructions thoroughly.
These instructions are for installation
with studs on 16" centers.
(1)
E
C
B
(3)
(2)
F
G
Rough Wall Opening:
• 11 1/8" Wide
• 15 3/8" High
• 4" Min. Depth
A
H
D
1
SCOTT
PRO
™
®
Door
A
Back Housing
B
Instructions
C
Trim Ring
D
Silver Core Plug
E
Black Swing Arm Plugs
F
Key
G
Retaining Clips
H
034135 • 9/2019
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kimberly-Clark PROFESSIONAL SCOTT PRO
Summary of Contents for Kimberly-Clark PROFESSIONAL SCOTT PRO
- Page 1 Installation instructions for the KIMBERLY-CLARK PROFESSIONAL SCOTT ™ ® STAINLESS STEEL RECESSED DISPENSING SYSTEMS Code: 31501 IMPORTANT! For secure mounting, follow instructions thoroughly. These instructions are for installation Rough Wall Opening: with studs on 16” centers. • 11 1/8” Wide •...
- Page 2 Installing the Stainless Steel Unit, Recessed in Wall - 31501 Materials Required: • Manual or electronic module • (2) 2 x 4” ’s for framing • Tape measure • (2) 1 x 4” ’s for framing • Combination Square • Hammer •...
- Page 3 7. Test the fit of the dispenser in the hole. (Figure 8) 8. Determine if additional framing is needed for the install. For jobs on 16 inch centers, additional framing will be needed. Use 2 x 4” ‘s and 1 x 4” ‘s and balance the framing on each side as needed.
- Page 4 13. Add the retaining rings commonly known as “c” clips on the hinges for the door to keep the cover in place. (Figure 16 & 17) 14. Close the door. (Figure 18) 15. Add the use label that comes with the dispenser, it is now ready to use.
