CD Automation
1.3 Communication Terminals 300-700A (S12-S13-S14)
1.3.1 RS485 Serial Port
The serial communication port RS485
is available on the Command Terminals.
On this port may be done a network
up to 127 REVO C.
Terminal M1
Description
7
RS485 A
8
RS485 B
1.4 Fieldbus communication option
Other serial communication port are available as option.
Communication Manual
Revo C
5
