Malmbergs 99 190 25 Installation And Instruction Manual

HF Aisle Sensor with DALI Control 99 190 25
1. Technical Specifications
Product type Independent DALI sensor (Daylight harvest)
Operating voltage 120~277VAC 50/60Hz
Switched power 2 x 2000W (resistive) 2 x 800W (capacitive)
Power consumption < 1W
o
Detection angle 360
Detection range 10% / 50% / 100%
Hold time 2s / 30s / 1min / 5min / 10min / 30min
Stand-by time 0s / 10s / 1min / 10min / 30min / +
Stand-by dimming level 10% / 20% / 30%
Daylight threshold 2 ~ 50Lux , Disable
Warmming-up time 20s
o
Operating temperature -20 C ~ +50
IP rating IP65
3. Functions
3.1 Daylight Harvest (Daylight Regulating)
Daylight sensor measures the available surrounding natural light, calculates how much electrical light is
needed to reach the total lux expected. The demand is given to the LED driver by DALI signal, so as to
deliver the needed amount of electric light.
Light level
Energy Saving Zone
0
3.2 Dry Contact Control
Sometimes also know as "Potential-Free" or "Volt-Free" sensor, the dry contact sensors from Hytronik are
designed to operate with external monitoring systems. They operate as conventional occupancy sensors, with
the output available as shown in the table below:
Detection State Contacts Made
No - Com
Presence
Absence Nc - Com
3.3 Loop-in and loop-out
Double "L" "N" terminal makes it easy for wire loop-in and loop-out, and saves the cost of terminal block and
assembly time.
5. Detection Pattern
5 2 m x 6 m o c e v a r e g @ 8 m m u o i t n g n e h g i
www.malmbergs.com
Art.no: 99 190 25
Installation and Instruction Manual
o
C
Hold time
Normal Electric Light
Stand-by time
4 2
t h 5 2 m x 6 m o c
2. Instruction and Dimension
Warnings:
1. Installation of the sensor involves connecting it to the mains supply. This work must be
carried out by a specialist in accordance with electrotechnical regulations.
2. Disconnect supply before installing.
L N L N
1
Installation rack
Daylight controlled light
Natural light
Varning!
Stäng av strömmen, ta ut säkringen på elcentralen eller ställ automatsäkringen till läge "AV", innan
Time (hrs)
installationsarbetet påbörjas.
Skall installeras av behörig installatör och i enlighet med gällande föreskrifter.

4. Wiring Diagram

N
L
99 190 25
e v a r e g @ 5 1 m m u o i t n g n e h g i t h
1-10V+ DALI -
1-10V - +
DALI
L N
2
N
N C
O
C OM
Daylight sensor
Infrared remote receiver
LED indication
Sensor Antenna
Wire out
N
L
N
L
1
N
L
2
1-10V +
1-10V -
DALI +
DALI -
N
C
C
OM
N
O
0 5 m e d e t i t c n o e l g n h t @ 5
115.4
135
56
114
N
L
1-10V +
LED Driver
1-10V -
+
DALI
DALI -
N
L
1-10V +
LED Driver
1-10V -
DALI +
DALI -
Power
m m u o i t n g n e h g i t h
2017.03.01
