UART with IrDA ENDEC

The ZNEO Z16F Series contains a fully-functional, high-performance
UART with Infrared Encoder/Decoder (ENDEC). The Infrared ENDEC is
integrated with an on-chip UART (component U13) allowing easy com-
munication between the ZNEO Z16F Series and IrDA transceivers. Infra-
red communication provides secure, reliable, low-cost, point-to-point
communication between PCs, PDAs, cell phones, printers, and other
infrared enabled devices.
UM020205-0908
12-bit Pulse Width Modulator (PWM) module with three
complementary pairs or six independent PWM outputs with dead-
band generation and fault trip input
Three standard 16-bit timers with capture, compare, and PWM capa-
bility
Watchdog Timer (WDT) with internal RC oscillator
Up to 76 I/O pins
Up to 24 interrupts with programmable priority
Single-pin on-chip debugger
Power-on Reset (POR)
Voltage Brownout Protection (VBO)
2.7 V to 3.6 V operating voltage with 5 V tolerant inputs
0 °C to +70 °C standard temperature, -40 °C to +105 °C extended
temperature, and -40 °C to +125 °C automotive operating ranges
®
ZNEO Z16F Series Development Kit
®
Z16F Series Product Specification
ZNEO Z16F Series Development Board
User Manual
