6 AVENTICS | Marex 3D | R417003106–BDL–001–AA
About this documentation
Table 4:

Designations

Designation
Marex 3D
Joystick
1.3.2
The following symbols mark notices which are not relevant to
safety but contain useful knowledge for the proper operation of
the product.
Table 3:
Symbol
1.
2.
3.
1.3.3
The following abbreviations are used in these assembly
instructions:
Meaning
Electronic remote control for ship propulsions including thrusters
Operating element for 3D and thruster mode
1.3.4
The following abbreviations are used in these assembly
instructions:
Table 5:
Abbreviation
CAN
AI
AO
DI
DO

Symbols

Meaning of symbols
Meaning
If this information is not observed, the optimal use or
operation of the product cannot be ensured.
Single, independent step
Numbered instructions:
The numbers indicate the steps which must be executed
in a given order.
Designations

Abbreviations

Abbreviations
Meaning
Controller Area Network
Asynchronous serial bus system to link control units.
Analog input
Analog output
Digital input
Digital output
