  • Page 1 Assembly instructions Marex 3D 3D Controller R417003106/04.2018, Replaces: –, EN...

  • Page 2: Table Of Contents

    AVENTICS | Marex 3D | R417003106–BDL–001–AA Table of Contents Table of Contents About this documentation ..........4 Validity of the documentation..........4 Required and additional documentations......4 Presentation of information ........... 4 1.3.1 Safety messages ..............5 1.3.2 Symbols ..................6 1.3.3...
  • Page 3 AVENTICS | Marex 3D | R417003106–BDL–001–AA Table of Contents Disposal ............... 19 Technical data ............. 19 Appendix ..............21 12.1 Installation drawings..............21 Alphabetical Index ............23...

  • Page 4: About This Documentation

    They contain important information for properly and safely installing and dismantling the 3D Controller. The 3D Controller is a component of the Marex 3D ship control system. Refer to the documentation on Marex 3D for information on the start-up and operation.

  • Page 5: Safety Messages

    AVENTICS | Marex 3D | R417003106–BDL–001–AA About this documentation manner. For easy understanding, explanations are provided in the following sections. 1.3.1 Safety messages This documentation includes safety instructions placed before a sequence of actions during which there is a risk of damage to persons or property.

  • Page 6: Symbols

    AVENTICS | Marex 3D | R417003106–BDL–001–AA About this documentation 1.3.2 Symbols The following symbols mark notices which are not relevant to safety but contain useful knowledge for the proper operation of the product. Table 3: Meaning of symbols Symbol Meaning If this information is not observed, the optimal use or operation of the product cannot be ensured.

  • Page 7: Safety Instructions

    Intended use The 3D Controller is used to process analog and digital control signals within the ship control system Marex 3D. It is designed for the application in the engine room on board of boats, yachts and commercial vessels. The 3D Controller must only be...

  • Page 8: Personnel Qualifications

    AVENTICS | Marex 3D | R417003106–BDL–001–AA Safety instructions created in the application which may cause damage to persons and/or property. Therefore only apply a product within applications relevant to safety if this kind of use is clearly specified and permitted in the product's documentation as for example within explosive areas or in parts of a control system which are relevant for functional safety.

  • Page 9: Product- And Technology-Related Safety Messages

    You must not modify or convert the 3D Controller. Persons who install, operate, dismantle or maintain AVENTICS products must not be under the influence of alcohol, other drugs or medications which affect the responsiveness.

  • Page 10: General Notes Regarding Property Damages And Product Damages

    Risk of injury or property damage due to unsuitable cables Using unsuitable cables can lead to errors or malfunctions in the Marex 3D system. Only use cables supplied by AVENTICS. These provide – EMC shielding – a perfect data transmission –...

  • Page 11: Scope Of Delivery

    Product description The 3D Controller is the control unit of Marex 3D. The commands which are set by the joystick are transmitted to the 3D Controller via the joystick CAN bus. The 3D Controller processes and converts the signals and thus actuates engines and thrusters in an intelligent way.
  • Page 12 AVENTICS | Marex 3D | R417003106–BDL–001–AA Product description 3460690410 Fig. 1: 3D Controller, material No. 1 Removable cover 2 Fixing screws for the cover 3 Mounting bores 4 Covered terminal openings 5 CANbus connectors Fig. 2: 3D Controller 3460690410, inside view Refer to the 3D manual for more information on the 3D Controller, see chapter 1.2, Required and additional...

  • Page 13: Product Identification

    AVENTICS | Marex 3D | R417003106–BDL–001–AA Transport and storage Product identification A product type plate can be found at the bottom of every 3D Controller and on its packaging. The type plate contains the following information: Fig. 3: Type plate of the 3D Controller...

  • Page 14: Delivery Check

    AVENTICS | Marex 3D | R417003106–BDL–001–AA Transport and storage Delivery check Check the supply immediately on receipt for completeness and transport damage. Proceed as follows if any visible damage is discovered during receipt of delivery: – Do not accept the delivery or only under reservation.

  • Page 15: Assembly

    Improper installation work can cause accidents or damage to property. The 3D Controller may only be installed by AVENTICS or qualified personnel as specified in chapter 2.4. Install or uninstall the 3D Controller only if the component and the system are powered off.

  • Page 16: Mounting The 3D Controller

    See also fig 4 for the dimensions. Free space for terminal plugs: 120 mm Fig.. 4: 3D Controller, 3460690410, installation space Refer to the Marex 3D manual to establish the electrical connections. See also chapter 1.2, Required and additional documentations.

  • Page 17: Maintenance And Repair

    AVENTICS | Marex 3D | R417003106–BDL–001–AA Maintenance and repair Maintenance and repair Cleaning Cleaning of the 3D Controller is not required. Inspection Connections might loosen after a period of time. Check the 3D Controller at regular intervals for visible damage and loose screws.

  • Page 18: Disassembly And Replacement

    Risk of injury and property damage when servicing components under power If you dismantle or replace the 3D Controller while Marex 3D is in operation, the ability to steer may be lost. Components may be destroyed if connections are removed under power.

  • Page 19: 10 Disposal

    AVENTICS | Marex 3D | R417003106–BDL–001–AA Disposal Observe the project documentation. Make sure the power is switched off before starting the work. 10 Disposal NOTICE Environmental damage due to improper disposal Electronic components require special waste treatment and must only be disposed of by approved specialist companies.
  • Page 20 AVENTICS | Marex 3D | R417003106–BDL–001–AA Technical data Table 6: Technical data of 3D Controller 3460690410 Applied EMC standards: EN 60945:2002 Maritime Navigation and Radiocommunication Equipment and Systems - General Requirements - Methods of Testing and Required Test Results Germanischer Lloyd (2003)

  • Page 21: 12 Appendix

    AVENTICS | Marex 3D | R417003106–BDL–001–AA Appendix 12 Appendix 12.1 Installation drawings Fig. 5: 3D Controller, 3460690410, dimensions Free space for terminal plugs: 120 mm Fig. 6: 3D Controller, 3460690410, dimensions...
  • Page 22 AVENTICS | Marex 3D | R417003106–BDL–001–AA Alphabetical Index 13 Alphabetical Index Numerics 3D Controller, figure 12 Improper use 7 3D Tuning, manual 4 Inspection 17 Installation conditions 15 Instruction Manual Marex Abbreviations 6 3D 4 Additional Intended use 7 documentation 4...

  • Page 23: Alphabetical Index

    AVENTICS | Marex 3D | R417003106–BDL–001–AA Alphabetical Index QR-code 4 Validity of Qualifications 8 documentation 4 Repair 17 Replacement 18 Required documentation 4 Safety instructions, general 8 Safety messages 5 Scope of delivery 11 Standards 20 Storage 14 Storage period 15...
  • Page 24 German language. R417003106–BDL–001–AA/04.2018 Subject to modifications. © All rights reserved by AVENTICS GmbH, even and especially in cases of proprietary rights applications. It may not be reproduced or given to third parties without its consent.
