HC 403 EU, HC 403 MK • Setup Guide (Continued)
Front Panel Operation and Indications
Input Selection and Indication
Input selection button and LED
•
To select an input on the transmitter, connect a cable with an active video signal to the connector for that input.
•
To select receiver input 1 from the receiver front panel, push the input 1 button (see
The corresponding LED lights to indicate that that input is selected (active).
Use the auto-switching feature, which is active by default. In the "last connected" auto switch mode, the system automatically
switches to the input where an active AV source device was last connected. If that device is disconnected, the system switches to
the last device connected before that, as long as it has an active signal.
Signal, HDCP, and Audio LEDs
Signal LEDs — These LEDs (
corresponding input connector. If there is no active signal, the LED is unlit.
HDCP LEDs —These LEDs (
with HDCP encryption at the corresponding input connector. Because input 2 on the
transmitter is analog video, it does not support HDCP, so there is no HDCP LED for
transmitter input 2.
HDCP LED State and Indication
On (Lit Steadily)
An HDCP encrypted TMDS signal is detected at the
corresponding input.
Audio input signal LEDs (LPCM-2Ch and Multi-Ch)— These two LEDs (
the presence or absence of the specific types of audio signal on the selected (active) input.
Audio Input LED State and Indication
Audio
LED Type
On (Lit Steadily)
LPCM-2Ch
An embedded LPCM-2Ch audio signal is
present on the selected HDMI TMDS input.
Multi-Ch
Multi-Ch or bitstream (non-PCM) audio is
present on the selected HDMI TMDS input.
OSD Use
See the section on page 9 of this guide about configuring the AV settings using the on-screen display and front panel buttons,
and see the HC 400 Series User Guide for full details on the OSD and how to use it.
Locking the Front Panel (Executive Mode)
To prevent unauthorized access or accidental changes to device settings, you can lock the front panel controls, making control
available only by software. (The default state is unlocked.)
•
You can lock and unlock the front panel by using a control in the PCS software.
•
Front panel lockout (Executive) mode 2 can also be enabled and disabled by pressing and holding the Menu and Enter
buttons for 2 or more seconds.
Firmware Upgrades
The firmware can be upgraded via the HCR 102 embedded web page, or via Extron Toolbelt software (available at
www.extron.com).
16
C
) light to indicate the presence of an active signal at the
D
) light to indicate the presence of an active signal
figure
Off (Unlit)
An unencrypted TMDS signal is detected at the
corresponding input or no active TMDS signal is detected.
E
) on the receiver indicate
Off (Unlit)
There is no LPCM-2Ch audio signal in the selected TMDS input.
There is no TMDS signal on the selected input.
The audio embedded in the selected input is in Multi-Ch format.
There is no Multi-Ch audio signal in the selected TMDS input.
There is no TMDS signal on the selected input.
The audio embedded in the selected input is in LPCM-2Ch format.
B
2,
on the HCR 102).
Input 3
1
SIGNAL
PWR
HDCP HDMI VGA
AUTO
HDCP
HCR 102
HCT 102 EU/MK
Receiver
Receiver
AUDIO
LPCM-2CH
MULTI-CH
1
Input 2
