HC 403 EU, HC 403 MK • Setup Guide (Continued)
Digital I/O
To use digital input or output to control other devices, provide
feedback to the receiver, or trigger actions, connect devices to
the digital I/O ports ( M
DIGITAL I/O
HCR 102
Rear Con gure each port as a digital input or output,
Panel with or without +5 VDC pull-up. Use these ports to:
1 2 G 3 4 G
• Monitor or trigger events and functions (toggle relays,
• Trigger LEDs, incandescent lights, or other devices
Ground
Switch,
G
4 Sensor
3
G
Indicator
2
LED
1
HDMI/CEC
Connect an AV device that supports CEC control to the
HDMI/CEC output port on the receiver (
to automatically turn display power on or off based on whether
an active signal is detected at the selected input.
The HCR 102 sends CEC driver commands to the display for
basic control functions. CEC control is pre-configured and works "out of the box" but it can be customized further using GC.
NOTE: It can take up to 2 minutes after powering up the receiver to initiate CEC display control.
14
) as shown in the following diagram.
Digital I/O (digital input/output)
issue commands, send e-mail), once con gured.
that accept a TTL signal.
Share the
same ground
among I/O
Wire
connections.
Nut
Device 4
Device 3
Device 2
Device 1
G
) to allow the HCR 102
LAN
Connect the receiver to a network via the LAN port (
for remote monitoring and configuration of the system,
for touchpanel control, or to allow the receiver to control an
Ethernet-enabled product. You will need the MAC address
( O ) during device discovery and configuration.
Insert Twisted
RJ-45
Connector
Activity
LED
2 2 2
(Switches,
sensors,
LEDs,
relays, or
-XX-XX-XX -XX-XX-XX X
E###### E###### #
similar
items)
HCR 102 Rear Panel
OUTPUTS
L I LINK L I N N N K K K
HDMI/CEC
HCR 102 Rear Panel
Ethernet
TCP/IP
Network
Pair Wires
NOTE: Initial units ship with
the functions of these LEDs
reversed. Subsequent
units will ship with
standard LED functions.
LAN (Ethernet)
Default protocol:
• IP address: 192.168.254.250
Pins:
• Gateway IP address: 0.0.0.0
8 7 6 5 4 3 2 1
• Subnet mask: 255.255.255.0
Link
• DNS address: 127.0.0.1
LED
• DHCP: off
• Link speed and duplex level:
LAN
autodetected
• Data rates: 10/100Base-T
Default login credentials:
• Username: admin
LAN
• Password: extron
MODEL 80
A A A A AUDIO A U D U U D D D D D IO O O O
L L L L L L R R
HDMI
CEC
CEC-Compliant Display
N
)
PC
AV Device
FLAT PANEL
