Valor 752BTK Installation Instructions

May be combined with 751LTK Lift Trim Kit or 750OCP Oversize Closure Plate (sold separately)
Note: This kit must be installed or serviced by a qualified installer, service agency or gas supplier. These
instructions are to be used in conjunction with the main installation instructions for the above listed models.

Kit contents

Insert with Standard Trim

(base trim may also be used with
751LTK riser or 750OCP oversize plate)
752BTK Base Trim
Because our policy is one of constant development and improvement, details may vary slightly from those given in
this publication.
190 – 2255 Dollarton Highway, North Vancouver B.C., CANADA V7H 3B1
Tel. (604) 984-3496 Fax (604) 984-0246
4000268-04
#752BTK
Base Trim Kit
INSTALLATION INSTRUCTIONS
1-3/8" Total Rise
Designed and Manufactured by / for Miles Industries Ltd.
© Copyright Miles Industries Ltd., 2006
The Model 752 BTK is a 1-3/8" high black
sheet metal riser that fits beneath the
standard insert trim to raise the heater to
cover a higher fireplace opening. The Base
Trim may also be used with the 751 LTK Lift
Trim Kit to provide risers of greater height.
The 750 OCP Oversized Closure Plate may
also be combined with the Base Trim. The
recessed portion of the insert firebox will
require shimming (supplied by dealer) to
match the height of the riser.
(The G3 Insert is approved for shimming
constructed of combustible material.)
