Valor 784EC Installation Manual

INSTALLATION MANUAL
784EC Edgemont Craftsman Front Kit
with Backing Plates 799 (sold separately)
Use with Valor G4 780 and 785 models ONLY
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and must be
installed for the protection of children and other at-risk
individuals.
The 784EC Edgemont Craftsman Fronts are intended
to be used on Valor heater model 780 and 785 with a
required choice of Backing Plate: 3-Sided 799BPB-1,
799BPB-2, 799BPB-3, 799STB-1, 799STB-2, or 4-Sided
799BPB-4S.
Mounting of the 784 affects cavity dimensions—see
next page and installation manual supplied with the
appliance for more information.
784EC front including doors
Overview (G4 and 3-sided 799 backing plate)
4007858-04
©2023, Miles Industries Ltd.
G4
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
G4 fireplace
799 Backing Plate
(sold separately)
INSTALLER: Leave this
manual with the appliance.
CONSUMER: Retain this
manual for future reference.
Note: This kit must be
installed or serviced by a
qualified installer, service
agency or gas supplier. These
instructions are to be used
in conjunction with the main
installation instructions
for the above listed heater
model.
!
Please note the appliance will have to be raised
by 2-13/16" when using the 799BPB-4S 4-Sided
Backing Plate as the plate extends below the
bottom of appliance.
Overview (G4 and 4-sided 799 backing plate)
G4 fireplace
799BPB-4S
Backing Plate
(sold separately)
784EC front including doors
