Preparation
1.3

Product Description

Anybus Wireless Bridge II provides wireless communication over WLAN and/or
Bluetooth
Typical applications for Anybus Wireless Bridge II include:
• Adding wireless cloud connectivity to industrial devices
• Accessing devices from a laptop, smartphone or tablet
• Ethernet cable replacement between devices
Note:
Bluetooth PAN (Personal Area Network) may not work with some devices due to
different implementations of Bluetooth by different manufacturers.
WLAN 5 GHz cannot be used at the same time as WLAN 2.4 GHz or Bluetooth.
1.4 Model Name – Certification Identifier
The model name consists of a model prefix followed by two designators for
interface configuration and functionality.
Prefix
Interface configuration
Functionality
Example: AWB3AA = Anybus Wireless Bridge II with internal antenna, Ethernet
networking and digital input.
Anybus ® Wireless Bridge II
®
to wired networks.
AWB3
A
B
A
B
™ Startup Guide
Anybus Wireless Bridge II
Internal antenna, Dual M12
External antenna, Dual M12, RP-SMA
Ethernet with digital input
Ethernet w/o digital input
SCM-1202-013/SP2167 EN 1.9
4 (16)
