Technical Data

4 Technical Data
4.1

Hardware Specifications

Order code
Wired Interface type
Antenna
Maximum range
Dimensions (LxWxH)
Weight
Operating temperature
Storage temperature
Humidity
Vibration
Pressure
Housing material
Protection class
Mounting
Power connector
Ethernet connector
Power supply
Power consumption
Anybus ® Wireless Bridge II
AWB3000
Ethernet
3 internal antennas:
2.4 GHz
2.4 GHz MIMO
5 GHz
400 m (WLAN and Bluetooth)
93 x 68 x 33.2 mm
120 g
-40 to +65 °C
-40 to +85 °C
EN 600068-2-78: Damp heat, +40 °C, 93 % humidity for 4 days
See datasheet
850 to 1050 mB
Plastic (see data sheet for details)
IPX5
Screw mount or DIN rail using optional clip
M12 male A-coded
M12 female D-coded
9–30 VDC (-5 % +20 %)
Cranking 12 V (ISO 7637-2:2011 pulse 4)
Reverse polarity protection
0.7 W (idle), 1.7 W (max)
™ Startup Guide
AWB3010
1 external antenna:
2.4 GHz + 5 GHz dual band
