- Page 1 ® Anybus WLAN Access Point IP67 STARTUP GUIDE SP2383 1.3 en-US ENGLISH...
- Page 2 HMS Industrial Networks reserves the right to modify its products in line with its policy of continuous product development. The information in this document shall therefore not be construed as a commitment on the part of HMS Industrial Networks and is subject to change without notice.
-
Page 3: Table Of Contents
Table of Contents Page About This Document ........... . . 3 Document Conventions. - Page 4 This page intentionally left blank...
-
Page 5: About This Document
About This Document 3 (18) About This Document This document describes how to install Anybus WLAN Access Point IP67. For additional documentation and software downloads, FAQs, troubleshooting guides and technical support, please visit www.anybus.com/support. Document Conventions The following conventions are used to indicate safety information and other important content in this document: WARNING Instruction that must be followed to avoid a risk of death or serious injury. -
Page 6: Safety
Safety 4 (18) Safety General Safety Instructions Caution This equipment emits RF energy in the ISM (Industrial, Scientific, Medical) band. Make sure that all medical devices used in proximity to this device meet appropriate susceptibility specifications for this type of RF energy. This product contains parts that can be damaged by electrostatic discharge (ESD). -
Page 7: Ghz Transmission Power Restriction (Eu Only)
Safety 5 (18) 5 GHz Transmission Power Restriction (EU only) Transmission power must be reduced for 5 GHz channels 149-165 when the unit is used in the EU. To comply with the European Radio Equipment Directive (RED) the effective radiated power output for 5 GHz channels 149-165 (U-NII-3) must not exceed 25 mW (~14 dBm) when the unit is used in the EU. -
Page 8: Installation
Installation 6 (18) Installation The Anybus WLAN Access Point IP67 can be screw-mounted onto a stable flat surface using the included wall mounting kit. It can also be pole-mounted using the included adjustable steel band straps. For optimal reception, wireless devices require a zone between them clear of objects that could otherwise obstruct or reflect the signal. -
Page 9: Overview
Installation 7 (18) Overview Fig. 2 Overview 1, 2 Antenna connector (N) 3, 8 Threaded hole for grounding screw Ethernet connector (M12) Reset button LED indicators Power connector (M12) ® SP2383 1.3 en-US Anybus WLAN Access Point IP67 Startup Guide... -
Page 10: Wall Mounting
Installation 8 (18) Wall Mounting Fig. 3 Wall mounting Attach the mounting plate to the back of the unit using the 4 included screws. The plate can be attached vertically or horizontally. Hold the unit upright against the wall and fasten it with 4 screws through the apertures in the plate. -
Page 11: Pole Mounting
Installation 9 (18) Pole Mounting Fig. 4 Pole mounting Attach the mounting plate to the back of the unit using the 4 included screws. The plate can be attached vertically or horizontally. Thread the two supplied metal mounting straps through the large slots on the mounting plate and then put the straps around the pole. -
Page 12: Power Connector (M12)
Installation 10 (18) Power Connector (M12) The power connector is a 5-pin A-coded M12 type connector that supports dual power inputs with a common ground connection. Connecting power with reverse polarity or using the wrong type of power supply may damage the equipment. Make sure that the power supply is correctly connected and of the recommended type. -
Page 13: Ethernet Connector (M12)
Installation 11 (18) Ethernet Connector (M12) The Ethernet connector is an 8-pin A-coded M12 type connector. The Ethernet port supports PoE (Power over Ethernet) compliant with IEEE 802.3af. A Power over Ethernet power source is not included with the equipment. The power source must be UL (UL 62368-1) certified for UL compliance, fully compliant with IEEE 802.3af, marked “Limited Power Source”, “LPS”... -
Page 14: Ethernet Cabling
Installation 12 (18) Ethernet Cabling When planning a cable route from the access point (outdoors) to the power injector module (indoors), consider the following guidelines: • Determine a building entry point for the cable. • Determine if conduits, bracing, or other structures are required for safety or protection of the cable. -
Page 15: Led Indicators
Installation 13 (18) LED Indicators Fig. 5 LED indicators on bottom panel PWR1 Power supplied on Power Input 1 Green Power supplied on Power Input 2 PWR2 Green Power supplied on Ethernet port Green No LAN Green LAN link established Green, flashing LAN traffic No WLAN... -
Page 16: Configuration
Configuration 14 (18) Configuration Anybus WLAN Access Point IP67 is configured via a web interface which is accessed by pointing a web browser to the IP address of the unit. The computer accessing the web interface must be in the same IP subnet as the access point. Default web interface settings IP address 192.168.0.2... -
Page 17: Technical Data
When this product reaches its end of life, contact local authorities to learn about disposal and recycling options, or simply drop it off at your local HMS office or return it to HMS. For more information, see www.hms-networks.com. ®... -
Page 18: Dimensions
Technical Data 16 (18) Dimensions Fig. 7 Dimensions All measurements are in mm. ® SP2383 1.3 en-US Anybus WLAN Access Point IP67 Startup Guide... - Page 19 This page intentionally left blank...
