HMS Anybus Wireless Bridge II Startup Manual page 12

Configuration
3.2.1 Easy Config Modes
EC
1 A
2
A B
3
4
5 A
6
7 A B C
8
9 A
10
11 A B
The Easy Config modes are also described in detail when selected in the web
interface.
Anybus ® Wireless Bridge II
LED Role
Bluetooth PANU
B
–
–
C
Client
C WLAN AP
B C Bluetooth NAP
WLAN AP
D Bluetooth NAP
D Bluetooth PANU
D (any)
B
D (any)
™ Startup Guide
Description
Configure as a client and scan for another
client (PANU to PANU).
Reset configuration to factory defaults.
Reset IP settings to factory defaults.
Wait for automatic configuration.
Configure units in mode 4 as clients.
Restart as access point and connect clients.
Configure units in mode 4 as clients.
Restart as access point and connect clients.
Apply PROFINET optimization to all units.
Configure as a client and scan for another
client (PANU to PANU).
Apply PROFINET optimization to both units.
Apply PROFINET optimization and restart.
Enable PROFIsafe mode.
SCM-1202-013/SP2167 EN 1.9
