- Page 1 Anybus ® WLAN Access Point IP30 STARTUP GUIDE SP2382 EN 1.1 ENGLISH...
-
Page 2: Important User Information
The data and illustrations found in this document are not binding. We, HMS Industrial Networks AB, reserve the right to modify our products in line with our policy of continuous product development. The information in this document is subject to change without notice and should not be considered as a commitment by HMS Industrial Networks AB. -
Page 3: About This Document
About This Document 3 (12) About This Document This document describes how to install the Anybus WLAN Access Point IP30 and set up a basic configuration. For additional documentation and software downloads, FAQs, troubleshooting guides and technical support, please visit www.anybus.com/support. Document Conventions The following formatting conventions are used in this document to indicate safety information and other content of specific importance:... -
Page 4: Installation
Installation 4 (12) Installation Caution This equipment emits RF energy in the ISM (Industrial, Scientific, Medical) band. Make sure that all medical devices used in proximity to this device meet appropriate susceptibility specifications for this type of RF energy. This product contains parts that can be damaged by electrostatic discharge (ESD). - Page 5 Installation 5 (12) Overview Power connector 2, 6 Antenna connectors Digital inputs Digital outputs Console connector (not used) Ethernet connectors Reset button WLAN signal LEDs Status LEDs Anybus ® WLAN Access Point IP30 Startup Guide SP2382 EN 1.1...
-
Page 6: Power Connector
Installation 6 (12) Connectors 2.2.1 Power Connector Connecting power with reverse polarity or using the wrong type of power supply may damage the equipment. Make sure that the power supply is connected correctly and of the recommended type. The power connector consists of a 6-pin terminal block located on the top of the unit. -
Page 7: Ethernet Connectors
Installation 7 (12) 2.2.2 Digital In/Out Connectors Anybus WLAN Access Point IP30 has 4 digital inputs and 4 digital outputs that can be used for monitoring and controlling purposes. See the description of the DIDO settings in the User Manual for more information. Digital Inputs Function Direct input 1... -
Page 8: Led Indicators
Installation 8 (12) LED Indicators PWR1 Power input 1 Green Power input 2 PWR2 Green FAULT General error No WLAN link Green WLAN link established WLAN Green, flashing WLAN traffic Strong WLAN signal 4 LEDs 2–3 LEDs Adequate WLAN signal 1 LED Weak WLAN signal All unlit... - Page 9 Configuration 9 (12) Configuration Anybus WLAN Access Point IP30 is configured through a web interface which is accessed by pointing a web browser to the IP address of the unit. The default IP address is 192.168.0.2. The computer accessing the web interface must be in the same IP subnet as the access point.
-
Page 10: Technical Data
When this product reaches its end of life, contact local authorities to learn about disposal and recycling options, or simply drop it off at your local HMS office or return it to HMS. - Page 11 Technical Data 11 (12) Dimensions All measurements are in mm. Anybus ® WLAN Access Point IP30 Startup Guide SP2382 EN 1.1...
- Page 12 © 2018 HMS Industrial Networks Box 4126 300 04 Halmstad, Sweden info@hms.se SP2382 EN 1.1 / 2018-08-20 / 9139...
