Land Rover Range Rover Vogue
* Facelift models, with touchscreen
INTERFACE FEATURES
• Provides accessory power
• Designed for amplified models
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Micro "B" USB updatable
INTERFACE COMPONENTS
• AX-LR90082 interface
• AX-LR90082 amplifier interface
• ASWC-1 interface
• AX-LR90082 harness
• ASWC-1 harness
• M.O.S.T. jumper harness
• Female 3.5mm connector with stripped leads
AxxessInterfaces.com
Data Interface with SWC
(with M.O.S.T. 25 amplifier)
© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION
AX-LR90082
I N S TA L L AT I O N I N S T R U C T I O N S
2006-2012*
TABLE OF CONTENTS
Connections To Be Made .......................................2
Installing The Ax-Lr90082 Interface.....................3
Programming The Aswc-1 Interface .....................3
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
REV. 6/21/18 INSTAX-LR90082
Advertisement
Table of Contents
Related Manuals for Axxess AX-LR90082
Summary of Contents for Axxess AX-LR90082
- Page 1 2006-2012* TABLE OF CONTENTS (with M.O.S.T. 25 amplifier) Connections to be made ........2 * Facelift models, with touchscreen Installing the AX-LR90082 interface.....3 Programming the ASWC-1 interface .....3 INTERFACE FEATURES • Provides accessory power • Designed for amplified models • Provides NAV outputs (parking brake, reverse, speed sense) TOOLS REQUIRED •...
- Page 2 CONNECTIONS TO BE MADE From the aftermarket radio to the AX-LR90082 harness: • Eclipse: Connect the steering wheel control wire, normally Brown, to the Brown/White wire of the connector. Then connect the remaining steering wheel control wire, normally • Connect the Black wire to the ground wire.
- Page 3 Manufacturer corresponds to which flash. • Connect the AX-LR90082 harness to the wiring harness in the vehicle. * • Connect the ASWC-1 harness to the ASWC-1 interface, and then to the AX-LR90082 interface. L.E.D. feedback legend • Connect the M.O.S.T. jumper harness to the factory fiber optic cable from the display screen.
- Page 4 AX-LR90082 I N S TA L L AT I O N I N S T R U C T I O N S IMPORTANT PROGRAMMING THE ASWC-1 INTERFACE (CONT.) If you are having difficulties with the installation of this product, please call our Tech Support line at 1-800-253-TECH.
