Axxess AX-LCD Installation Instructions

Axxess LCD screen 2000-up
INTERFACE FEATURES
• Retains the personalization menu that
is lost when removing the factory radio
(select applications)
INTERFACE COMPONENTS
• LCD Screen
• DIN harness with leads
APPLICATIONS
(For retaining the personalization menu that is lost when removing the factory radio)
TOYOTA
Camry 2012-2014
APPLICATIONS
(For retaining and controlling the factory satellite radio while using an Axxess Interface)
BUICK BUICK
Century 2004-2005 Rainier
LaCrosse 2005-2009 Rendezvous
• Retains and controls the factory satellite
radio while using an Axxess interface
(select applications)
FIAT
Fiat 500 L 2014-2016
BUICK
2004-2007 Terraza
2002-2007
• Adjustable 256 color LCD screen
• Wire channel for flexible mounting
• Micro "B" USB updatable
MAZDA
Mazda6 2014-2015
CADILLAC
2005-2008 Escalade/ESV/EXT 2003-2006
Applications continued on the next page
AX-LCD
I N S TA L L AT I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Connections to be made .......................................3
Using the LCD screen .........................................4-5
TOOLS REQUIRED
• Cutting tool • Crimping tool • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
