The operating instructions are intended for all persons who operate the RBW322-FTL-902 for the purpose of increasing the reliability and the service life of the device; it should also help prevent hazards, downtime and possible exclusion of warranty claims.
Adhesive pad ■ Installation note: RBW322-FTL-902 Safety Always observe the following in order to operate the RBW322-FTL-902 room control module correctly and safely: ► Read all warnings in these operating instructions in order to prevent injuries and damage to the device or any equipment connected to it.
Do not operate the device in a potentially explosive environment. ► Do not open the device. ► Only operate the RBW322-FTL-902 when it is in original condition. Modifications to the device could result in unforeseeable dangers and are thus prohib- ited. Issue 2015-01-09...
MD15-FTL-902 radio partner), you must inform your service technician. Equipment Description You can use the RBW322-FTL-902 room control module to measure the room temperature in resi- dential or commercial buildings, and to wirelessly transfer measured values, occupancy, setpoints and weekly schedules to the MD15-FTL-902 radio small actuator.
Packaging, transportation and storage 3.1 Components Display Displays information on the current status of the RBW322-FTL-902/MD15-FTL-902 functional unit. Setting knob For switching on the device for the first time and for selecting values. Solar cell Generates energy for device operation Occupancy button Select between “Present”...
In this operating mode, only economy mode is active. See para- graph "Summer mode", page 12. In the configuration menu of RBW322-FTL-902 Room Control Module you can set the type and date of the operating modes you want to use. See chapter 7.3 “Configuration Menu”, page 13.
Controls and Display 6.2 Indicators on the display The RBW322-FTL-902 has a large display with clear indicators and icons for displaying current information about the room control module. Time, temperature or Initial display, can be configured setpoint Energy storage unit The “Energy storage unit”...
Operations and Settings Operations and Settings Settings can be made by both the service technician and the operator in the following working menus. The working menus are not restricted by an access code. 7.1 Summer mode When the sun icon is displayed, it indicates that the device is oper- ating in summer mode.
Operations and Settings 7.3 Configuration Menu The following functions are available on the configuration menu: ■ Setting party mode (usage time extension) ■ Setting vacation mode ■ Ending an active vacation mode early ■ Deleting or ending vacation mode ■ Setting the weekly schedule ■...
Operations and Settings ► Turn the setting knob to set the end time for party mode. The bar display shown indicates the set comfort mode extension (usage time extension). ► Press the setting knob. The display switches back to the initial display. Comfort mode extension is effective immediately.
Operations and Settings Setting the setpoint ► Set the setpoint for the vacation time. ► Press the setting knob. The display switches back to the initial display. Vacation mode begins on the set start date at 12 a.m. and ends on the set end date at midnight.
Operations and Settings ► Press the setting knob. First usage time/Start time appears on the display and flashes; the icon is active. ► Turn the setting knob. ► Set the start time. ► Press the setting knob. First usage time/End time appears on the display and flashes; the icon is active.
Operations and Settings 7.3.5 Setting the setpoints for comfort mode and economy mode ► Press the setting knob for 2 seconds. ► Turn the setting knob clockwise. ► Select the “Setpoint” function (temperature display). ► Press the setting knob. The setpoint for comfort mode flashes and can now be set. icon is active.
Operations and Settings 7.3.7 Setting the time, temperature or setpoint as the initial display ► Press the setting knob for 2 seconds. ► Use the setting knob to select the “Setting the initial display” function dISP. ► Press the setting knob. ►...
The RBW322-FTL-902 does not require regular maintenance. If operating or malfunction messages arise, carry out the actions described in the section “Malfunctions” on page 19. 8.2 Cleaning The RBW322-FTL-902 should be cleaned as necessary. There is no prescribed cleaning interval. ►...
Page 20
Malfunctions ■ Radio communication with at ► Check the battery level of the MD15-FTL-902. least one taught-in radio ► Replace the batteries in the partner has been interrupted for MD15-FTL-902 if necessary or more than four hours and a contact your service technician. synchronization has failed.
Decommissioning, Removal and Disposal 10 Decommissioning, Removal and Disposal 10.1 Decommissioning The RBW322-FTL-902/MD15-FTL-902 functional unit must be decommissioned before transportation, storage or long periods of disuse. For decommissioning, you must reset the device to the factory settings. With these settings, the device no longer sends out wireless signals.
Decommissioning, Removal and Disposal 10.2 Removal 10.2.1 Screw mounting If you want to remove the room control module, proceed as follows: ► Insert the flat screwdriver into the notch between the room control module and the holding plate on the right side. ►...
The device RBW322-FTL-902 room control module is an electrical device with lithium batteries and a solar cell. The RBW322-FTL-902 room control module therefore may not be disposed of with household waste, it may only be disposed of in appropriate recepta- cles or at designated collection points.
11.3 Wireless interface Wireless communication with the MD15-FTL-902 is cyclical, bidirectional and includes an intelligent teach-in process. If the wireless communication between the RBW322-FTL-902 and the MD15-FTL-902 is interrupted, a new teach-in procedure is automatically triggered internally. NOTE This device uses only EnOcean radiograms.
Technical Specifications 11.4 Type plate The RBW322-FTL-902 type plate is located on the back of the device, behind the holding plate. RBW322-FTL-902 type plate Serial number Identification number Frequency Device approval number (USA) Device name Issue 2015-01-09...
IEEE Std. 1528-2003 December 2003. Class A digital device or peripheral The RBW322-FTL-902 is a digital device that is marketed for use in a commercial, indus- trial or business environment, exclusive of a device which is marketed for use by the general public or intended to be used in the home.
Contact data Type of antenna: integrated/onboard PCB-antenna, permanently attached Gain of the antenna: ≤ -10 dBi Frequency range: 902 MHz 13 Contact data Magnum Energy Solutions LLC 43 Village Way #209 Hudson, OH 44236 (+1) (330) 656 9365 (telephone) (+1) (866) 271 3961 (toll free) (330) 656 9368 (fax) Issue 2015-01-09...
